Product Operation & Specifications
Though testing was performed under standard laboratory conditions, the actual performance of the
system may vary based on local water conditions and quality.
SPECIFICATIONS
Model WF150K
Hydrostatic Test Pressure 350 psi (24.15 bar)
Working Pressure Limits (minimum/maximum)
20 ~ 125 psi
(1.38 ~ 8.62 bar)
Water Temperature Limits (minimum/maximum)
33.8 ~ 102.2 °F
(1 ~ 39 °C)
Required Riser Pipe Diameter 1.050 inch (26.7 mm)
Electrical Adapter
Input: AC120V, 60Hz
Output: AC12V, 650mA
Pressure Tank Thread 2 1/2″ NPSM
Inlet/Outlet Connector 3/4″ NPT
*Independent 3
rd
party laboratory test data.
