Isuzu 4LC1 Repair Manual

GENERAL INFORMATION 19
GASKET LOCATION
1. LOCATIONS WHERE GASKETS ARE USED
Gasket; nozzle holder
Gasket; joint bolt
Gasket;
nozzle holder
Corrugated
washer
Gasket; heat shield
Gasket;
water outlet pipe
Gasket;
idle spring set screw
Gasket;
governor
cover
O-ring;
fuel cut lever
O-ring;
control lever
O-ring;
angleich cover
Oil seal;
crankshaft front
Gasket;
rear cover
(PTO)
O-ring;
Oil pump
O-ring;
Oil strainer
O-ring;
Oil drain plug
Gasket;
exhaust silencer
Gasket;
exhaust
manifold
Oil seal;
crankshaft
rear
Gasket;
cylinder head
Seal; valve
Gasket; headcover
(※)Sealant should not be
applied.
Fig. 19
