ITech IT6322B User Manual

Function and Features
Copyright © Itech Electronic Co., Ltd. 14
When button is lit, means you can set voltage.
When button is lit, means in current setting mode.
When button is lit, means in recall mode.
When button keeps flickering, means in save mode and waiting for
a number to be entered to specify the memory location.
When button is lit, means current VFD displays actual voltage and
current.
When button is lit, means at least one channel output is on. Or all
channels are in OFF mode.
NOTE
, , buttons will not be lit at the same time.
3.2 Local/Remote Operation Switching
The power supply provides two modes of operation, local operation and
remote operation. The two operating modes can be switched between
communication commands. The initialization mode is the local operation
mode.
 Local operation mode: In the local operation mode, all the buttons can be
used. Use the buttons on the front panel to perform related operations.
 Remote operation mode: The power supply is connected to the PC, and
the related operation is performed on the PC. When in the remote
operation mode, the other buttons on the panel do not work except the
Meter and Local buttons. You can switch to the local operating mode by
pressing the Local button. When the operating mode is changed, the
output parameters of the power supply are not affected.
3.3 Channel Operation
When or button is lit, press (Local) key can switch
between the three channels.
3.4 OUT ON/OFF
Pressing button toggles the output state of all 3 channes of the
power supply. If the output state is ON, press it, to turn the output state to OFF.
While the output state is OFF, press and the power supply output
will turn ON.
To control channels individually, press (Shift)+ , (Shift)+ ,
(Shift)+ corresponding to each channel. (Shift)+ controls the
output state of the first channel, (Shift)+ controls the output state of the
second channel, (Shift)+ controls the output state of the third channel.
When the power supply is in remote mode, you can set the output state by
sending SCPI command (OUTPut: ON | OFF). The output state operation
does not affect any other parameter.
V-setV-set
I-setI-set
Recall
MeterMeter
On/Off
V-setV-set
I-setI-set
Recall
V-setV-set
I-setI-set
On/Off
On/Off
1
2
3
1
2
3
