Example:
When you set the output voltage as 60V, because
the max power of IT6720 is 100W, so the max output
current is 100W/60V=1.6A.
When you change the output voltage to 30V, the output
current is 100W/30V=3.2A.
Calculate according to the above way when the output
voltage is 20V, the output current should be 5A, but as
the max rating current of IT6720 is 8A, so the nal max
output current is 5A.
1
2 3 4 5
20
40
60
I
V
Power
100%
Function
•
Fully digital control
•
High resolution 10mV/1mA in Full range
•
Low ripple and noise
•
Bright and easy to read display (LED)
•
Constant current and constant voltage output
•
High reliability OVP/OCP/OTP protection
•
Output on/off control
•
Best performance /price ratio
•
Storage for 4*100 preset voltage and current output
4 USER’S GUIDE
IT6720 output curve
