D 9.11 View Details of Brake Paddles Parts
13
14
15
16
17
18
19
20
21
22
23
24
No.
1
2
3
4
5
6
7
8
9
10
11
12
Qty.
DESCRIPTION
Reference No. Qty.
DESCRIPTION
Reference
30014116AA
10010439AC
10080077AA
20002549AA
10006738AB
10010523AB
10004498AA
0431030036
04020200030
10005187AA
10080078AB
10080874AA
04030800012
0403040008
10080071AC
04040708065
04030800010
04010102025
10080079AA
10010437AE
10010438AD
10010524AB
10080072AC
10080073AC
RUBBER PAD
BRAKE PEDAL ASSY (RIGHT)
ADJUSTABLE TIE ROAD (FOR BRAKE PEDAL)
CIRCLIP 25*1.2N.I:S3075 (PART-1)
WASHER (BRAKE PEDAL)
TENSION SPRING (BRAKE ASSY.)
FELT RING
SEALING WASHER DIA 30*36*2
EXTERNAL CIRCLIP
LINK PIN
ADJUSTABLE TIE ROAD
LINK PIN
3
1
2
2
2
2
3
3
3
8
2
2
MICD WASHER DIA 13*25 DIA 24*2.5
SPRING WASHER
BRAKE PEDAL SHAFT (ASSY.)
HEX BOLT M8*1.25*65
M/CD WASHER DIA 10.5*DIA 21*2
SPLIT PIN DIA 2*25
ADUSTABLE TIE ROAD FOR CLUTCH PEDAL
CLUTCH PEDAL ASSY.
BRAKE PEDAL ASSY (LEFT)
TENSION SPRING (CLUTCH ASSY)
LUG ASSEMBLY (LEFT)
LUG ASSEMBLY (RIGHT)
2
1
1
1
8
10
1
1
1
1
1
1
