Technical information
Technical information
Model Greenline HT Plus C/E 6 C/E 7 C/E 9 C/E 11 E 14 E 17
Emitted /Supplied output at 0/35°C
1
kW 5,9/1,3 7,3/1,6 9,1/2 10,7/2,2 14,4/3,1 16,7/3,7
Emitted /Supplied output at 0/50°C
1
kW 5,4/1,7 6,9/2,1 8,4/2,6 10,1/3,0 13,9/4,2 16,2/4,9
Minimum fl ow heating medium l/s 0,14 0,18 0,22 0,26 0,35 0,40
Nominal fl ow heating medium l/s 0,20 0,25 0,31 0,37 0,50 0,57
Permitted ext. pressure drop heating
medium nominal fl ow
kPa363634335451
Nominal fl ow cooling medium l/s 0,30 0,38 0,46 0,57 0,78 0,90
Permitted ext. pressure drop cooling
medium nominal fl ow
kPa494544807471
Max pressure radiator system bar 1,5
Max pressure cooling medium system bar 4
Highest outgoing heating medium
temperature
°C 65
Operating temperature heat transfer system °C -5 to +20
Integrated heat/HTF pump Yes
Electrical supply 400V 3N~ 50Hz
Add. heat reconnectable kW 3.0 / 6.0 / 9.0
Recommended fuse size depends on
electrical additional heat
2
Electric cassette 6 kW
Electric cassette 9 kW
A161620202025
A202025252532
Compressor Scroll
Refrigerant R407C kg 1,35 1,4 1,5 1,9 2,2 2,3
Connection, heating medium Cu 22 22 22 22 28 28
Connection, cooling medium Cu 28 28 28 28 35 35
Dimensions E-model (WxDxH) mm 600x600x1520
Weight E-model kg 146 152 155 170 190 195
Dimensions C-model (WxDXH) mm 600x600x1800 - -
Weight C-model
Copper/Stainless hw-cylinder kg 230/200 231/201 240/210 218 - -
Integrated double-shelled HW-cylinder on
the C-model. Copper or stainless
3
Copper /
stainless
Copper /
stainless
Copper /
stainless
Stainless - -
Domestic hot water C-model litres 165 165 165 165 - -
Control unit Rego637
1
Output data at 0/35°C and 0/50°C and min heating medium fl ow are stated according to the European standard
EN 255. Additional heat not included.
2
Melt fuse breaker type gL-gG or miniature circuit breaker with characteristic C.
3
Anode included with C-models with stainless hot water cylinder.
