Maintenance Manual for J2 Sedan
Electrical Part of Engine
144
2) Check
①
 Solenoid switch
■
Before
check,
disconnect
negative
terminal
of
battery.
■
Disconnect
the
“M”
port
of
starter.
a. Test
electrical
connectivity
between
“S”
port
and switch body.
■
Replace
solenoid
switch
if
opened.
b. Test electrical connectivity between “S”
port
and “M” port.
■
Replace
solenoid
switch
if
opened.
②
 Pinion
a.
Visual
inspection
of
the
meshing
gear
teeth
■
If the
teeth are
worn or
damaged, replace
meshing gear (check
teeth
of fly
wheel in
this step).
b. Check
the
teeth
of
pinion
■ If the teeth are
worn or
damaged, replace pinion (check
teeth
of rotor shaft gear in t
his step).
c.
Check
whether the
pinion locks
in
one
direction while
turns smoothly
in
the
other direction.
■
If it
is able
to lock
or turnable
in both
directions, or
if there
is
abnormal resistance,
replace.
Fig. 3.2.006
Fig. 3.2.007
Connecting from
the power
supply
“M”
“M” end
Connecting from
the power supply
