12
Turfcat
T628D
ENGINE OIL
See Engine Manual for manufacturer's
recommendations. Before using the machine for the
first time, check the oil level in the engine crankcase
with the crankcase dipstick. When checking oil level,
make sure the machine is on level ground.
To change engine oil:
1. First warm up the engine. Shut off engine when
warm, remove oil drain plug P and drain the oil
from the sump.
2. Clean plug and replace.
3. Re-fill sump with the recommended engine oil.
4. Always check level of oil on the dipstick. To
obtain the correct measurement, the machine
should be on level ground.
NOTE: After the oil has been added, wait one minute
and then check level of oil again with the dipstick.
To change engine oil filter:
The oil filter cartridge O is easily reached from the
right side of the tractor. It should be replaced
complete with each oil change. Apply a thin film of oil
to the seal when replacing the cartridge and check for
leaks after starting the engine. Top off oil if
necessary.
AIR CLEANER
Clean and replace the air cleaner element as
specified in the service chart. Uneven running, lack of
power or black exhaust fumes may indicate a dirty air
cleaner.
To replace air cleaner element:
1. Unclamp end cover Y and remove existing
cleaner element.
2. Insert new element Z and replace end cover.
Ensure arrows on end cover are pointing
vertically upwards.
MAINTENANCE
