GB-11
JACOBSEN AR3/TR3
TOPS FITTING INSTRUCTIONS
4137350 AR3/TR3T OPS Kit (ABT) Consists of:
1 AR3-01 Roll Bar AR3/TR3 1
2 * Label 1
3 XB12045Z-10.9 Hex Bolt - M12 x 45 Gd 10.9 8
4 XB10045Z-10.9 Hex Bolt - M10 x 45 Gd 10.9 2
5 XN12-10SZ Hex Nut (Stover M12) 8
6 XN10-10SZ Hex Nut (Stover M10) 2
7 XW12BZ Plain Washer M12 8
8 XW10BZ Plain Washer M10 2
9 4137585 Seat Belt Kit-AR3 / TR3 1
4137585 Seat Belt Kit-AR3 / TR3 TOPS Incl items 1 to 4
1 4133937 Seat Belt Assembly 1
2 * Scrw-Hex 7/16" x 20 x 1 2 order Kit 4135347
3 * Nut-Hex Lock 7/16" x 20 2 order Kit 4135347
4 * Wshr - 1/2" x 1 1/4" x 0.104 2 order Kit 4135347
Items 2,3 & 4 only available buy ordering
Kit No. 4135347
5 PARTS LIST
No Part Number Description Qty Remarks
LMAC164
