Jandy CL340 User Manual

SECTION 9. Parts List and Exploded View
10
9.1 Jandy® CL Cartridge Filter Parts List
Key
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Description
Handle Assembly w/ hardware (set of 2)
Handle Hardware (set of 4)
Gauge/Air Release Assembly
Pressure Gauge
Tank Adapter w/O-ring
Tank Top CL580
Tank Top CL340 & CL460
Top Space
Breather Tube Assembly
Manifold Assembly
CL 580 Filter Cartridge, 145 sq. ft. (4 required)
CL 460 Filter Cartridge, 115 sq. ft. (4 required)
CL 340 Filter Cartridge, 85 sq. ft. (4 required)
Tank Clamp Ring w/ Retainer Assembly
Clamp Retainer Assembly
Tank O-ring
CL580 Outlet Tube/Elbow Assembly w/ O-rings
CL460 & CL340 Outlet Tube/Elbow Assembly
w/ O-rings
Bulkhead Assembly w/ O-ring
Coupling Nuts w/ Flange and O-ring (set of 2)
Inlet Elbow w/ O-ring
Tank Bottom
Drain Plug w/ O-ring
Filter Cartridge Support
O-ring Replacement Kit (not shown)
Installation/Instruction Manual (not shown)
Safety Labels (not shown)
ORDER
PART NO:
R0357100
R0359900
R0357200
R0569600
R0552000
R0357300
R0554700
R0357700
R0358700
R0357600
R0357900
R0554600
R0554500
R0357400
R0357500
R0357800
R0358100
R0555100
R0358200
R0327300
R0358400
R0358600
R0358800
R0358500
R0358000
H0238700
R0387400
