No.
14
Frequency Response: 30Hz – 22kHz –6dB
Sensitivity: 95dB for 2.83V @ 1 meter
Recommended Maximum 200 watts continuous
Power Handling: 800 watts peak
Nominal Impedance: 6 ohms
Crossover Frequencies: 340Hz, 1300Hz, 8000Hz
Low-Frequency Transducer: ME150H
Mid-Frequency Transducer: 2123H
High-Frequency Transducer: 275ND
Ultrahigh-Frequency Transducer: 2405H
Tuning Frequency of Woofer: 32Hz
Dimensions (HxWxD): 41-3/8 x 25 x 17"
1051 x 635 x 432 mm
Weight: 180 lbs
82 kg
System Specifications
4344 MK 11 Manual 7/21/98 3:18 PM Page 13
