JBL BAR STUDIO User Manual

2
TABLE OF CONTENTS
1. INTRODUCTION 3
2. WHAT’S IN THE BOX 3
3. PLACE YOUR SOUNDBAR 3
PLACE THE SOUNDBAR ON THE TABLE 3
WALL MOUNT THE SOUNDBAR 3
4. CONNECT YOUR SOUNDBAR 4
CONNECT SOUNDBAR TO YOUR TV 4
CONNECT SOUNDBAR TO OTHER DEVICES 4
HOW TO POWER ON YOUR SOUNDBAR SYSTEM 4
5. USE YOUR SOUNDBAR SYSTEM 4
TO CONTROL 4
HOW TO USE BLUETOOTH WITH YOUR SOUNDBAR 5
HOW TO USE A USB DEVICE 5
6. SOUND SETTING 6
BEFORE YOU START 6
ADJUST THE VOLUME 6
CHOOSE SOUND EFFECT 6
7 . RESPOND TO YOUR TV REMOTE CONTROL 6
FOR MOST SAMSUNG, LG, SONY AND VIZIO TVS 6
FOR OTHER TVS 7
8. SYSTEM 7
1. AUTO STANDBY 7
2. AUTO WAKE UP 7
3. APPLY FACTORY SETTING 7
4. SOFTWARE UPDATE 7
9. PRODUCT SPECIFICATIONS 7
GENERAL 7
INPUT AND OUTPUT 7
BLUETOOTH SECTION 7
PRODUCT DIMENSION AND WEIGHT 7
10. TROUBLESHOOTING 8
SYSTEM 8
SOUND 8
BLUETOOTH 8
REMOTE CONTROL 8

JBL BAR STUDIO Specifications

General

Audio decoders	-
RMS rated power	30 W
Audio output channels	- channels
Surround modes quantity	1
Number of woofer drivers	2
Woofer diameter (imperial)	2 \
Signal-to-Noise Ratio (SNR)	90 dB
Tweeter diameter (imperial)	1.5 \
Subwoofer included	No
Bluetooth	Yes
HDMI version	1.4
Bluetooth version	4.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Product color	Black
Cables included	AUX, Optical

Weight and Dimensions

Depth	86 mm
Width	614 mm
Height	58 mm
Soundbar weight	1400 g
