JBL BAR STUDIO User Manual

3
www.jbl.com
English
1. INTRODUCTION
Thank you for purchasing the JBL BAR STUDIO. The JBL BAR
STUDIO is designed to bring an extraordinary sound experience
to your home entertainment system. We urge you to take a few
minutes to read through this manual, which describes the product
and includes step-by-step instructions to help you set up and get
started.
CONTACT US: If you have any questions about JBL BAR
STUDIO, its installation or its operation, please contact
your retailer or custom installer, or visit our website at:
www.JBL.com.
2. WHAT’S IN THE BOX
Soundbar
x1
Remote Control
Battery size of remote control: CR2025
x1
Power Adaptor
(4ft, 1200mm)
x1
Power Cables*
(5ft, 1500mm)
x1
*Power cable types and numbers varied by regions
Optical Cable
(4ft, 1200mm)
x1
AUX cable
(4ft, 1200mm)
x1
Wall Mount Brackets
x1
Product Information & Wall-mounted guide
x1
3. PLACE YOUR SOUNDBAR
3a. Place the Soundbar on the table
3b. Wall mount the Soundbar
Use tape to stick the wall-mounted paper guide on the wall, push
a pen tip through the center of each mounting hole to mark the
wall-mounted bracket location and remove the paper.
Screw the wall mount brackets on the pen mark; screw the
threaded mounting post into the back of the soundbar; then hook
the soundbar on the wall.

JBL BAR STUDIO Specifications

General

Audio decoders	-
RMS rated power	30 W
Audio output channels	- channels
Surround modes quantity	1
Number of woofer drivers	2
Woofer diameter (imperial)	2 \
Signal-to-Noise Ratio (SNR)	90 dB
Tweeter diameter (imperial)	1.5 \
Subwoofer included	No
Bluetooth	Yes
HDMI version	1.4
Bluetooth version	4.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Product color	Black
Cables included	AUX, Optical

Weight and Dimensions

Depth	86 mm
Width	614 mm
Height	58 mm
Soundbar weight	1400 g
