JBL Control Control One Pro User Manual

System:
Frequency Range (-10 dB): 80Hz - 20kHz
Frequency Response (+/- 3 dB): 100Hz - 18kHz
Power Capacity
1
: 150 W
Sensitivity
2
: 87dB SPL, 1 W 1m (3.3 ft)
Maximum SPL
3
: 108dB continuous, 114dB peak
Directivity Factor (Q)
2
: 6.0
Directivity Index (DI): 7.8dB
Nominal Impedance: 4 ohms
Crossover Frequency: 4.2kHz
Overload Protection: Full-range SonicGuard™ power limiting to
protect network and transducers
Transducers:
LF Driver: 135mm (5.25 in) low frequency loudspeaker
HF Driver: 19mm (.75 in) polycarbonate dome tweeter
Enclosure:
Enclosure Material: Polypropylene Structural Foam
Finish: Black or White
Dimensions: 235mm x 159mm x 143mm
(9.25 in x 6.25 in x 5.6 in)
Net Weight (each): 1.8 kg (4 lbs)
Shipping Weight (pair): 4.6 kg (10 lbs)
Included Accessories: Mounting Bracket Assembly
1
IEC Standard, full bandwidth pink noise with 6 dB crest factor; 2 hour duration
2
Average 1 kHz to 10 kHz
3
Calculated based on power rating exclusive of power compression
JBL continually engages in research related to product improvement. Changes introduced into existing
products without notice are an expression of that philosophy.
8500 Balboa Boulevard
Northridge, CA 91329 USA
Visit us online at www.jblpro.com
© 2006 JBL Professional
P/N 363221-001
0706 REV B
Specifications

JBL Control Control One Pro Specifications

Audio Specifications

frequency range	80Hz - 20kHz
frequency response	100Hz - 18kHz
power capacity	150 W
sensitivity	87dB SPL, 1 W 1m (3.3 ft)
maximum SPL	108dB continuous, 114dB peak
directivity factor	6.0
directivity index	7.8dB
nominal impedance	4 ohms
crossover frequency	4.2kHz

Transducers

LF driver	135mm (5.25 in) low frequency loudspeaker
HF driver	19mm (.75 in) polycarbonate dome tweeter

Enclosure and Dimensions

enclosure material	Polypropylene Structural Foam
dimensions	235mm x 159mm x 143mm (9.25 in x 6.25 in x 5.6 in)
net weight	1.8 kg (4 lbs)
shipping weight	4.6 kg (10 lbs)
