General| Max SPL Output | 127 dB |
|---|---|
| Coverage Pattern | 90° x 60° |
| LF Driver | 15-inch |
| Dimensions | 707 x 439 x 365 mm (27.8 x 17.3 x 14.4 in) |
| Weight | 17.69 kg (39 lbs) |
| System Type | Self-powered 15", two-way, bass-reflex |
| Crossover Frequency | 1.8 kHz |
| Enclosure | Polypropylene |
| Frequency Response | 50Hz - 20kHz |
| Frequency Range | 55Hz - 20kHz |
| HF Driver | 1-inch |
| Input Impedance | 10 kΩ |
| LF Driver Details | 15" Woofer |
| HF Driver Details | JBL 2414H-1 1" compression driver |
| Suspension / Mounting | M10 suspension points |
| Inputs | 2 x XLR-1/4" combo |
| Outputs | XLR |
