JBL ES250PW Service Manual

Part Number Description Qty Reference Designator
MISCELLANEOUS/MECHANICAL
195-443391EV-E Bipolar LED (Cabinet) 339-1EVGW(339-1SURSYGW/S350-
A
1 D401
128-C117JA01-E electrolytic CAP 110uf 100V 1 Soldered to Woofer terminals
123-11K4DRH-E Ferrite core K4DRH 16*28.5*9 (RoHS) 3
123-11RH633215-E Ferrite core K5ARH 6.35*3.2*15.8(RoHS) 1
150-R1107011A-E Power Transformer 120V(RoHS) 1
153-VPST101S2-E VDE 2PINS INLETSOCKET PRONIC (RoHS) 1
162-10090003-E Wire 90mm20AWG 1
162-10129004-E Wire UL161720AWG 1
162-10130005-E Wire 1007# 24AWG 125mmBLK Tin 5mm RoHS 1
162-5016D001-E WIRE 24# 160mm bk (RoHS) 1
162-5018D007-E Wire 180mm 2pin 22AWG(RoHS) 1
162-5019D002-E Wire +Ferrite core 190mm P=2.54mm(RoHS) 1
162-5054D001-E Wire 540mm P=2.54mm(RoHS) 1
166-5070A4BD-E Speaker wire 700mm #18 1
180-P3024DB-E Power Switch ROCKER 3024-DB(RoHS) 1
188-ASDWLAN01-E RF ANTENNA ASSEMBLY ASD-WLAN-01 (RoHS) 1
193-0S4211-E (INSULATION SPACER)42*11 (RoHS) 1
193-201612TR-E NSULATION SPACER T0-220 16mm*12mm(RoHS) 3
236-AL-05001-0LAE RITAINER (RoHS) 1
302-AL-05169-1BAE Rear panel 300*200*2.5mm ES250PW/120V(RoHS) 1
306-ABS-05079-0BAE Rear plastic tube 198*298*102H (RoHS) 1
311-ABS-00028-0BAE Knob 46077-W P.V.C.(RoHS) LEVEL, CROSSOVER 2
325-FE-00400-0LAE PCB stand 58*9*13.5T (RoHS) 1
333-EVA-00188-0BAE EVA 170x5x1t (RoHS) 2
333-EVA-00220-0BAE EVA225*15*1t UL(RoHS) 1
333-EVA-00866-0BAE EVA 48*18*1.5T (RoHS) 1
333-EVA-05782-0BAE EVA 90*5*1mm (RoHS) 1
335-NYL-00002-0BAE WIRE CLKP 4K-4 NO-BB(RoHS) 1
336-RUB-05103-0BAE RUB gasket 97*16*3.0T bk(RoHS) 2
350-EM04012D024-E 4￠*12 WOOD SCREW BLACK (RoHS) 4
351-AM02606A011-E M2.6*6 Machine screw cross BLK(RoHS) 2
351-AM03008A078-E M3*8 Machine screw with nickel(RoHS) 10
351-AM03008A079-E M3*8 Machine screw cross BLK (RoHS) 9
351-AM03018A364-E Machine screw SCREW M3*18 BLK (RoHS) 2
351-HM03006A308-E Machine screw M3*6mm cross BLK (RoHS) 1
351-HM04010A217-E M4*10 Machine screw cross BLK (RoHS) 4
352-AM02606C1136-E Screw 2
352-AM03008D040-E 3*8 B type ping screw cross BLK (RoHS) 2
352-AM03008D041-E 3*8 Btype ping screw cross with nickel (RoHS) 2
352-AM03010D065-E 3*10 Ptype ping screw cross BLK(RoHS) 1
352-BM03010D064-E 3*10 Btype ping screw cross BLK(RoHS) 2
354-HM03005-E M3 nut 1
355-P07049-E Washer 7.2*12*0.5t (RoHS) 2
361-FE-00002-0LAE Bracket for Transformer 90*70*15mm (RoHS) 1
362-FE-00013-0LAE PCB stand L TYPE t=1.6mmS.P.C.C 89*9*1.6T (RoHS) 3
362-NYL-05049-0LAE PCB post M3 10H (RoHS) 2
29
ES250PW
