JBL GTO 24001 User Manual

GTO24001 Electrical Parts List
Part Number Qty Reference Designator
MAIN PCB
Resistors
RES68001/8-F Resistor METAL FILM 1/8WF680 OHM 1 R3
RES56001/8-F Resistor METAL FILM 1/8WF560 OHM 1 R4
RES78701/8-F Resistor METAL FILM 1/8WF787 OHM 1 R48
RES13011/8-F Resistor METAL FILM 1/8WF1.3K OHM 1 R44
RES15011/8-F Resistor METAL FILM 1/8WF1.5K OHM 1 R52
RES24011/8-F Resistor METAL FILM 1/8WF2.4K OHM 4 R150,151,214,215
RES32411/8-F Resistor METAL FILM 1/8WF3.24K OHM 1 R46
RES36011/8-F Resistor METAL FILM 1/8WF3.6K OHM 1 R47
RES43011/8-F Resistor METAL FILM 1/8WF4.3K OHM 1 R56
RES47011/8-F Resistor METAL FILM 1/8WF4.7K OHM 3 R20,71,73
RES62011/8-F Resistor METAL FILM 1/8WF6.2K OHM 1 R55
RES94011/8-F Resistor METAL FILM 1/8WF9.4K OHM 2 R22,23
RES91011/8-F Resistor METAL FILM 1/8WF9.1K OHM 1 R5
RES10021/8-F Resistor METAL FILM 1/8WF10K OHM 2 R36,89
RES13021/8-F Resistor METAL FILM 1/8WF13K OHM 1 R238
RES21021/8-F Resistor METAL FILM 1/8WF21K OHM 2 R35,91
RES22021/8-F Resistor METAL FILM 1/8WF22K OHM 4 R24,25,37,38
RES47021/8-F Resistor METAL FILM 1/8WF47K OHM 6 R26,27,28,30,54,74
RES2201/8-J Resistor CARBON FILM 1/8WJ22 OHM 5 R49,57,75,76,97
RES1011/8-J Resistor CARBON FILM 1/8WJ100 OHM 2 R19,68
RES1511/8-J Resistor CARBON FILM 1/8WJ150 OHM 2 R6,32
RES4711/8-J Resistor CARBON FILM 1/8WJ470 OHM 1 R80
RES5111/8-J Resistor CARBON FILM 1/8WJ510 OHM 2 R15,17
RES1021/8-J Resistor CARBON FILM 1/8WJ1K OHM 12 R39,42,45,60,65,92,121,149,173,191,202,236
RES1221/8-J Resistor CARBON FILM 1/8WJ1.2K OHM 1 R81
RES2021/8-J Resistor CARBON FILM 1/8WJ2K OHM 1 R1
RES2221/8-J Resistor CARBON FILM 1/8WJ2.2K OHM 5 R110,140,164,228,69
RES3321/8-J Resistor CARBON FILM 1/8WJ3.3K OHM 2
R59，240
RES4721/8-J Resistor CARBON FILM 1/8WJ4.7K OHM 10 R21,111,125,141,165,175,178,229,50,51
RES5111/8-J Resistor CARBON FILM 1/8WJ5.1K OHM 1 R11
RES5621/8-J Resistor CARBON FILM 1/8WJ5.6K OHM 2 R33,34
RES1031/8-J Resistor CARBON FILM 1/8WJ10K OHM 14 R8,10,18,31,62,64,66,79,90,95,126,176,185,239
RES1531/8-J Resistor CARBON FILM 1/8WJ15K OHM 4 R9,16,124,174
RES2031/8-J Resistor CARBON FILM 1/8WJ20K OHM 1 R40
RES2231/8-J Resistor CARBON FILM 1/8WJ22K OHM 3 R63,94,82
RES2731/8-J Resistor CARBON FILM 1/8WJ27K OHM 1 R96
RES3031/8-J Resistor CARBON FILM 1/8WJ30K OHM 1 R13
RES4731/8-J Resistor CARBON FILM 1/8WJ47K OHM 2 R29,43
RES5631/8-J Resistor CARBON FILM 1/8WJ56K OHM 2 R183,184
RES7531/8-J Resistor CARBON FILM 1/8WJ75K OHM 3 R53,70,72
RES1041/8-J Resistor CARBON FILM 1/8WJ100K OHM 7 R2,14,127,177,88,93,83
RES1041/8-J Resistor CARBON FILM 1/8WJ150K OHM 1 R7
RES1541/8-J Resistor CARBON FILM 1/8WJ1M OHM 3 R58,61,67
RES1001/4-J Resistor METAL FILM 1/4WJ10 OHM 32
R98,99,100,101,102,112,113,114,128,129,130,131,132,1
42,143,144,152,153,154,155,156,166,167,168,216,217,21
8,219,220,230,231,232
RES1511/4-J Resistor METAL FILM 1/4WJ150 OHM 20
R186,187,188,189,190,192,193,194,195,196,203,2
04,205,206,207,208,209,210,211,212
RES1041/4-J Resistor METAL FILM 1/4WJ100K OHM 32
R103,104,105,106,107,116,117,118,133,134,135,1
36,137,145,146,147,157,158,159,160,161,169,170,
171,221,222,223,224,225,233,234,235
RES2211/2-J Resistor METAL FILM 1/2WJ220OHM 2 R12,237
RES4721/0-J Resistor METAL FILM 1WJ4.7K OHM 2 R77,78
RESM2R2-J-2W Resistor MOR 2WJ(3.8x11m/m)2.2 OHM 3 R182,200,201
RESM470-J-2W Resistor MOR 2WJ(3.8x11m/m)47 OHM 4 R108,138,162,226
RESM101-J-2W Resistor MOR 5WJ(3.8x11m/m)100 OHM 2 R197,213
RESM222-J-2W Resistor MOR 2WJ(3.8x11m/m)2.2K OHM 3 R179,180,181
RESM472-J-3W Resistor MOR 3WJ(3.8x11m/m)4.7K OHM 4 R84,85,86,87
RESM472-J-2W Resistor MOR 2WJ(3.8x11m/m)4.7K OHM 2 R198,199
RESM221-J-3W Resistor MOR 3WJ(5.5x15m/m)220 OHM 4 R115,119,122,123
RESSR01-J-5W Resistor SHUNT 3LEAD 5W0.01 OHM 8 R41,109,120,139,148,163,172,227
RES0001/8-J Resistor
RES，CF 0R0 OHM 1/8W ±5%
1 R241
