OVERALLFREQUENCY RESPONSE
The frequency response of the output from the crossover system is shown in the figure below.
UDIO PRECISION
&vs
Crossover Response
-30.00
-25.00
-20.00
-15.00
-10.00
-5.000
0.0
5.0000
10.000
LEVEL(dBu) 2-CHAN(dBu)
20 100 1k 10k 50k
FREQ(Hz)
When a system under test shows a different result in the frequency response test, as shown
above, using a +4dBu input signal to the XLR connector with no DIP switches selected, the
source of the error can be investigated by referring to the following sections located within the
troubleshooting guide.
