Two-Way Speaker System Media 2
TABLE OF CONTENTS
Features..........................................................................1
Specifications .................................................................1
Disassembly Procedures................................................2
Trouble Shooting ............................................................2
Block Diagram ................................................................3
Master Speaker Exploded View (With Amplifier) ..........4
Slave Speaker Exploded View (Without Amplifier) .......5
Printed Circuit Boards ....................................................6
Electrical Parts List ........................................................7
Packaging Exploded View .............................................8
Integrated Circuits ..........................................................9
Media 2 Schematic Diagram........................................10
FEATURES
n
Two-way speaker system.
n
10-watt stereo amplifier.
n
Auto turn-on/turn-off circuitry.
n
Speakers are magnetically shielded for flicker-free use
alongside computer monitors.
n
For use with both Mac and PC-based computer systems.
n
Built-in electronic equalization for smooth frequency
response.
n
Variable bass contour control.
n Subwoofer output.
SPECIFICATIONS
Speaker System Full Range: ......Two-Way Speaker System
Speaker Size: ...........3"Woofer, 1.5" Tweeter
Total Amplifier Output Power: ......10Wat10%THD
Frequency Response: .........100Hz - 20kHz
Input Impedance: ..........50Kohms
Subwoofer Output Jack: ........Stereo mini plug (1/8")
Signal Input Jacks: ..........Stereo mini plug (1/8")
External Dimensions:
Height ..............11.5" (292mm)
Width ..............3.75" (95mm)
Depth ..............6"(152mm)
Weight:..............4lbsperpair
