Two-Way Speaker System Media 2
REF. NO. PART NO. DESCRIPTION QTY
Transistors
Q101, 102 1020945161 2SC945P 4
103, 104
Diode
D101, 102 125200032 IN4148 2
Diode (Zener)
ZD101, 102 1253000022 1/2W 9.1V (MTZ9.1B) 2
Diode (LED)
LD101 1257000041 2x5 m/m RED/GREEN 1
Integrated Circuits
U101, 103 1281000021 TLO74CN OP AMP 2
U102 1281000031 LA4700 POWER AMP 1
Resistor (Carbon)
R101, 102, 103, 1312033361 1/4W 33 KΩ ±5% 4
104
R105, 106 1312056361 1/4W 56 KΩ ±5% 2
R107, 108 1312012361 1/4W 12 KΩ ±5% 2
R109, 110, 111 1312010361 1/4W 10 KΩ ±5% 11
112, 123, 124,
130, 148, 149,
153, 156
R113, 114, 115, 1312027261 1/4W 2.7 KΩ ±5% 4
116
R117, 118 1312015161 1/4W 150 Ω ±5% 2
R119, 120, 121 1312010161 1/4W 100Ω ±5% 5
122, 134
R125, 126, 127, 1312022961 1/4W 2.2 Ω ±5% 4
128
R129, 150 1312022361 1/4W 22 KΩ ±5% 2
R131 1312033061 1/4W 33 Ω ±5% 1
R132 1312010061 1/4W 10Ω ±5% 1
R133 1312015261 1/4W 1.5 KΩ ±5% 1
R135, 136, 137, 1312010461 1/4W 100 KΩ ±5% 5
138, 147
R139 1312015461 1/4W 150 KΩ ±5% 1
R140, 141 1312022261 1/4W 2.2 KΩ ±5% 2
R142 1312018561 1/4W 1.8 KΩ ±5% 1
R143 1312018461 1/4W 180 KΩ ±5% 1
R144, 152 1312033161 1/4W 330 Ω ±5% 2
R145 1312039461 1/4W 390 KΩ ±5% 1
R146 1312082461 1/4W 820 KΩ ±5% 1
R151 1312068261 1/4W 6.8 Ω ±5% 1
R154 1312010261 1/4W 1 KΩ ±5% 1
R155 1312068161 1/4W 680 Ω ±5% 1
Capasitors (Electrolitic)
C101, 102, 103, 1546105112 50V 1 µF85°C ±20% 8
104, 111, 112,
113, 114
C117, 118, 119, 1542107112 10V 100 µF85°C ±20% 8
120, 121, 122,
128, 132
C129 1544107112 25V 100 µF85°C ±20% 1
REF. NO. PART NO. DESCRIPTION QTY
C130 1544228111 25V 2200 µF85°C ±20% 1
C131 1546475112 50V 0.47 µF85°C ±20% 1
C134, 138 1546106112 50V 10 µF85°C ±20% 2
C135, 136 1542227112 10V 220 µF85°C ±20% 2
Capasitors (Polyester)
C107, 108, 109, 1631683420 50V 0.0068 µF ±10% 4
110
C115, 116 1631472420 50V 0.0047 µF ±10% 2
C123, 124, 125 1631104420 50V 0.1 µF ±10% 4
126
Capasitors (Ceramic)
C105, 106 1723470142 50V 47PF CH ±5% 2
C133 1733221152 50V 220PF B ±5% 1
C139, 140 1733472272 50V 0.0047 µF F +8~-20% 2
C141 1733101142 50V 100PF CH ±5% 1
VR (Rotary)
VR101A, B 1951032402 10KBX2 1
VR102A, B 1951031601 10KAX2 1
PCB
2001300300 PCB, FIGURED 1.6T 94V-0 1
Speakers
2110040204 1-3/4" PEIZO SPEAKER 2
2110075303 12Ω 3" SHIELDED SPEAKER 2
Wires
2286053803 VINYL COAT WIRE 380-5-5 1
AWG24 UL1007 BLUE
2284053803 VINYL COAT WIRE 380-5-5 2
AWG24 UL1007 YELLOW
P103A, B 2282062203 VINYL COAT WIRE 220-5-5 1
AWG26 UL1007 RED
P104A, B 2285062203 VINYL COAT WIRE 220-5-5 1
AWG26 UL1007 GREEN
P105A, B 2280062203 VINYL COAT WIRE 220-5-5 1
AWG26 UL1007 BLACK
J101, 102, 111 2350607500 JUMPER WIRE 0.6∅ - 7.5 11
113, 115, 116,
117, 118, 119,
120
J103, 104, 109, 2350610000 JUMPER WIRE 0.6∅ -10 5
110, 112
J105, 106, 107 2350615000 JUMPER WIRE 0.6∅ -15 4
114
RB101A, B 2360100002 CONNECTIVE CORD 1
5C-100 AWG26 UL1007
RB102A, B 2360130001 CONNECTIVE CORD 1
4C-130 AWG26 UL1007
Jacks
JK101, 102, 103 2460103003 JACK (EAR), 3
3P ST-3.5∅-3P LJE0361-3RT
JK104 2460801004 JACK (DC) 2.0 DIA DC-014 1
JK105 2460601001 JACK (RCA), 1
1P RJ-1034-30BL-02
2460601002 JACK (RCA), 1
1P NUT TYPE SCJ-0363B
ELECTRICAL PARTS LIST
