9
Powered Subwoofer Media Sub
REF. NO. PART NO. DESCRIPTION QTY
Capacitors
C101 PRE3955-479 ELECT 4.7 uF 50V 20% 1
C102 PRD3545-101 DISC 100 pF 50V 10% 1
C103 PRE3951-101 ELECT 100 uF 10V 20% 1
C104, 105, 106 PRM3737-273 MYLAR 0.027 uF 100V 5% 4
107
C108 PRE3955-478 ELECT 0.47 uF 50V 20% 1
C110 PRE3952-100 ELECT 10uF 16V 20% 1
C111 PRE3951-221 ELECT 220 uF 10V 20% 1
C112 PRE3952-101 ELECT 100 uF 16V 20% 1
C113 PRE3955-109 ELECT 1uF 50V 20% 1
C114 PRD3545-471 DISC 470 pF 50V 10% 1
C115 PRD3545-331 DISC 330 pF 50V 10% 1
C116 PRE3951-101 ELECT 100 uF 10V 20% 1
C117 PRE3954-221 ELECT 220 uF 35V 20% 1
C118 PRD3545-101 DISC 100 pF 50V 10% 1
C119 PRE3955-109 ELECT 1 uF 50V 20% 1
C120 PRE3954-221 ELECT 220 uF 35V 20% 1
C121 PRD3545-102 DISC 1000 pF 50V 10% 1
C122 PRD3545-101 DISC 100 pF 50V 10% 1
C123 PRE3954-100 ELECT 10 uF 35V 20% 1
C124 PRD1335-220 DISC 22 pF 50V 5% 1
C126 PRM3737-104 MYLAR 0.1 uF 100V 10% 1
C128 PRE3952-101 ELECT 100 uF 16V 20% 1
C129 PRE3954-100 ELECT 10 uF 35V 20% 1
C130, 131 PVE3954-332 MYLAR 3300 uF 35V 20% 1
C132 PRE3952-221 ELECT 220 uF 16V 20% 1
C133 PRE3955-109 ELECT 1 uF 50V 20% 1
Connectors
RB102A CCN1500-035 10 PIN B10B-XH-A 1
POST BASE TOP
Diodes
D101, 102, 104 RAD4148-001 SW 1N4148 3
ZD102 RAZ0859-070 ZENR 5.6-5.9V 1
ZD101 RAZ0859-081 ZENR 11.9-12.4V
ZD103 RAD4001-001 RECTIFIER 1N4001 1A 35VRM 1
BD101 RHD0202-001 RECTIFIER BRIDGE RS202L 1
Integrated Circuits
IC101 RHI0740-001 14 PIN TL074CN Op Amp 1
IC102 RHI4558-001 8 PIN JRC4558D Op Amp 1
IC103 RHI4024-001 15 PIN STK4024 Power Amp 1
Transistors
Q101, 102, 103 RAN0945-001 NPN 2SC945P 6
106, 107, 108
Resistors
R101, 102, 103 QAF0650-103 10K Ω 1/6W ±5% 6
104, 105, 106
R107 QAF0650-393 39K Ω 1/6W ±5% 1
R108, 109 QAF0650-103 10K Ω 1/6W ±5% 2
R110, 112, 113 QAF0650-183 18K Ω 1/6W ±5% 3
R114 QAF0650-105 1.0M Ω 1/6W ±5% 1
R115 QAF0650-102 1K Ω 1/6W ±5% 1
R116 QAF0650-394 390K Ω 1/6W ±5% 1
R117 QAF0650-104 100K Ω 1/6W ±5% 1
R119 QAF0650-334 330K Ω 1/6W ±5% 1
R120 QAF0650-224 220K Ω 1/6W ±5% 1
R121 QAF0650-824 820K Ω 1/6W ±5% 1
R122, 123 QAF0650-103 10K Ω 1/6W ±5% 2
R124 QAF0650-102 1K Ω 1/6W ±5% 1
R125 QAF0650-152 1.5K Ω 1/6W ±5% 1
R126 QAF0650-152 1.5K Ω 1/6W ±5% 1
R127 QAF0650-330 33 Ω 1/6W ±5% 1
R128 QAF0650-103 10K Ω 1/6W ±5% 1
R129 QAF0650-562 5.6K Ω 1/6W ±5% 1
R130 QAF0650-563 56K Ω 1/6W ±5% 1
R131 QAF0650-821 820K Ω 1/6W ±5% 1
R132 QAF0450-101 100 Ω ¼W ±5% 1
R133 QAF0650-103 10K Ω 1/6W ±5% 1
R134 QAF0450-101 100 Ω ¼W ±5% 1
R135 QAF0650-563 56K Ω 1/6W ±5% 1
R136 QAF0250-331 330 Ω ½W ±5% 1
R137 QAF0250-479 4.7 Ω ½W ±5% 1
R138, 139, 140 QAF0650-103 10K Ω 1/6W ±5% 3
R146 QAF0450-100 10 Ω ¼W ±5% 1
R147 QAF0650-152 1.5K Ω 1/6W ±5% 1
R148 QAF0650-332 3.3K Ω 1/6W ±5% 1
R149 QAF0650-152 1.5K Ω 1/6W ±5% 1
R150 QAF0650-562 5.6K Ω 1/6W ±5% 1
R151 QAF0650-223 22K Ω 1/6W ±5% 1
R152 QAF0650-682 6.8K Ω 1/6W ±5% 1
R153 QAF0650-103 10K Ω 1/6W ±5% 1
R154 QAF0650-392 3.9K Ω 1/6W ±5% 1
R156 QAF0650-472 4.7K Ω 1/6W ±5% 1
R158 QAF0650-304 300K Ω 1/6W ±5% 1
R159 QAF0650-334 330K Ω 1/6W ±5% 1
R160, 161 QAF0650-103 10K Ω 1/6W ±5% 2
R162 QAF0650-223 22K Ω 1/6W ±5% 1
Miscellaneous
FLUX XFX0516-003 FLUX SM-35-10
SOLDER BAR XSD0515-001 60% TIN 40% LEAD
SOLDER WIRE XSD9143 0.05
THINNER FLUX XTN5714-002 ALPHA 425
THINNER OIL XTN5714-002 HOLLIS 225
RL101 MRL2212-003 RELAY OJE-SS-112DM 1
12V DC 37.5mA
WIRE, BARE AI20870-022 22 Ga Tinned
TRANSFORMER PARTS LIST
F101 KSA2100-001 FUSE 1A 250V
P103A to P103B 20565-122BB WIRE 22 Ga 120mm RED
P104A to P104B 20565-120BB WIRE 22 Ga 120mm BLACK
P105A to P105B 20565-122BB WIRE 22 Ga 120mm RED
P106, 107 XHP0001-001 L PIN
CABLE/WIRE VMC0001-006 MIC CABLE BLACK 9 FT PLUG 3.5”
FUSE CLIP CFC2557-001 5D 5x20
CONTROL JACK PCB PARTS LIST
ROTARY CONTROL MRR0103-001 10K W W/SW ON RED 1
JK101, 102 CJM9380-028 PHONE JACK JYE TAI 2
LD001 DSS0545-003 LED HOUSING 1
LD001 KEM0001-001 LED 1
R103, 104 QAF0650-103 RESISTOR 10 Ω 1/6W 5% 2
RB102B to RB102A 5003A2501B0 CON/WIRE 10 COND 250mm
ELECTRICAL PARTS LIST
