JBL MEDIA SUB Technical Manual

1
Powered Subwoofer Media Sub
TABLE OF CONTENTS
FEATURES.....................................................................1
SPECIFICATIONS..........................................................1
MEDIA SUB EXPLODED VIEW ...................................2
DISASSEMBLY PROCEDURES ...................................3
BLOCK DIAGRAM .........................................................4
PCB1&2(viewing trace layer through the board) .....5
PCB1&2(viewing silk-screen through the board) .....6
PCB 3 (viewing trace layer through the board) ............7
PCB 3 (viewing silk-screen through the board) ............8
ELECTRICAL PARTS LIST ...........................................9
PACKAGING EXPLODED VIEW.................................10
INTEGRATED CIRCUIT DIAGRAMS ..........................11
SCHEMATIC DIAGRAM ..............................................12
FEATURES
n
Powered subwoofer system.
n
25 watt amplifier.
n
Auto turn-on / turn-off circuitry.
n
Subwoofer is magnetically shielded for flicker-free use
near computer monitors.
n
Built-in electronic equalization for proper frequency
balance with satellite speakers.
n
Line level stereo output for use with satellite speakers
that don’t have a subwoofer output.
SPECIFICATIONS
Speaker System...........Sixth band-pass enclosure
Speaker Size............5.25” woofer
Total Amplifier Output Power ......25Wat10%THD
Input Sensitivity ...........250mV input for full power
Frequency Response .........40Hz - 150Hz
Input Impedance ..........10kohms
Signal Output jack ..........Stereominiplug jack (1/8")
Signal Input Jacks ..........Stereominiplug jack (1/8")
External Dimensions
Height ..............10.25"
Width ..............7.35"
Depth..............12"
Weight ..............12.8 lbs.
External Dimensions (metric)
Height ..............260mm
Width ..............186mm
Depth..............305mm
Weight ..............5.8kgs
