ENGLISH
-12-
LED Bar Indicators illuminate
in response to adjustments in
volume, delay, level, bass and
treble controls.
Status-Bar Indicators
Increase Decrease
Volume, Level, Delay
0dB
0dB
Increase Decrease
Bass, Treble

JBL Simply Cinema ESC 360 Specifications

Power

satellite power output	25 Watts x 5 @ 0.1% THD
subwoofer power output	60 Watts x 1 @ 1% THD

Audio

signal-to-noise ratio	80 dBA
frequency response	35Hz – 20kHz

Input Specifications

input impedance	20k Ohms
input sensitivity	400mV
auto turn-on sensitivity	2mV

Dimensions

satellite dimensions	111 x 81 x 92mm
subwoofer dimensions	315 x 300 x 310mm
