JBL Simply Cinema ESC 360 User Manual

ENGLISH
-8-
three. Operation
Master On/Off Switch
To operate unit, place this switch
in the On/Standby position. The
system will go into standby when
no signal has been received and
when no unit connected to any of
its two digital inputs has been on
for approximately five minutes.
Rear-Panel Control
Remote-Control-Battery Installation.
+
+
+
Push small tab towards
battery slot and pull battery
drawer out.
Remove old battery. Insert new battery with “+”
side up, and slide battery
drawer back into remote.

JBL Simply Cinema ESC 360 Specifications

Power

satellite power output	25 Watts x 5 @ 0.1% THD
subwoofer power output	60 Watts x 1 @ 1% THD

Audio

signal-to-noise ratio	80 dBA
frequency response	35Hz – 20kHz

Input Specifications

input impedance	20k Ohms
input sensitivity	400mV
auto turn-on sensitivity	2mV

Dimensions

satellite dimensions	111 x 81 x 92mm
subwoofer dimensions	315 x 300 x 310mm
