JBL Spot User Manual

6
6
Document Number: 950-0158-001 Description: JBL Spot Manual
Symptom
Possible Problem Solution
Troubleshooting
Check the connection of the wall adapter.
Place the wall adapter in a known powered outlet. Test
the outlet with a lamp or other device.
Connect JBL Spot to a known audio source. Test the
audio source with headphones.
Check the right satellite connection. Press it fi rmly into
the subwoofer.
Check the satellite connections. Press them fi rmly into
the subwoofer.
Adjust the Sub Level knob on the rear of the subwoofer
to the desired bass level.
No power; green LED is not on.
No volume control on right satellite.
No bass.
Wall adapter is not plugged into JBL Spot
correctly.
Wall adapter is not receiving AC power.
Right satellite is not plugged in correctly.
Left and right satellites are not connected
to correct subwoofer connector.
Incorrect bass setting.

JBL Spot Specifications

General

Type	Portable speakers
Power requirements	230 VAC
Number of satellite speakers	2
Satellite speakers RMS power	12 W
Subwoofer dimensions (WxHxD)	200 x 200 x 140 mm
Audio output channels	2.1 channels
Impedance	5000 Ω
Frequency range	40 - 20000 Hz
RMS rated power	36 W
Signal-to-Noise Ratio (SNR)	80 dB

Weight and Dimensions

Weight	2800 g
