Suspension in Fixed Installations (Secondary Suspension)
For fixed installations of SRX700F models using M10, forged-shoulder eyebolts, order JBL Part number 229-
00009-01 which includes 3 x 10 mm forged eyebolts with washers.
11
WARNING
Suspension of SRX700 speakers must employ
both top attachment points. When "bridling" an
SRX700,two (2) legs of equal length must be used.
The rear attachment point is a pull-back point and
is intended only for use in adjusting the down-
angle of the speaker enclosure. Only the top and
bottom attachment points are intended for use as
suspension points.
