JBL Sub 6 User Manual

SUB6 PART LISTS
SUB 6-MECHANICAL PARTS LIST
Ref No. Part No. Description Qty.
1 EVM0006-001 WOOD BOX 1
2 J1333B FRONT CAB (BLACK) 1
J1333W FRONT CAB (WHITE) 1
3 J3298A CNTL PANEL 1
4 J3404B PHASE KNOB (BLACK) 1
J3404W PHASE KNOB (WHITE) 1
5 J3402B FREQ. KNOB (BLACK) 1
J3402W FREQ. KNOB (WHITE) 1
6 J3403B VOL. KNOB (BLACK) 1
J3403W VOL. KNOB (WHITE) 1
7 J3400 REAR COVER 1
8 J2093B PORT EDGE 1
9 J2093A PORT TUBE 1
10 K4249 JACK PLATE 1
11 C6093B 6 1/2” WOFFER 1
12 TT11000-001 (100V) X’FORMER 1
TT11200-111 (120V) X’FORMER 1
TT112300-108 (230V) X’FORMER 1
13 K6250 X’FORMER BRACKET 1
14 K6251 X’FORMER PLATE 1
15 K6247 GRILLE (BLACK) 1
K6247W GRILLE (WHITE) 1
16 J3296/K6228A LOGO PLATE 1
17 E4219 AMP PCB ASS’Y 1
18 K6248 HEAT SINK (BLACK) 1
K6248W HEAT SINK (WHITE) 1
19 E4220 JACK PCB ASS’Y 1
20 E4216 VR/LED PCB ASS’Y 1
21 E4218 CON PCB ASS’Y 1
22 GSE0073-002 PCB BRACKET 1
23 E4214B FUSE HOLDER 1
24 47455-058 (100V) LINE CORD 1
47455-052 (120V) LINE CORD 1
2559-022022 (230V) LINE CORD 1
25 E4217 SW PCB ASS’Y 1
N1 HNI1482 NUT FOR PLT+X’FORMER BKT 1
P1 J3297F DRIVER GASKET 1
P2 J3297C PORT GASKET 1
P3 J3297D FRONT GASKET 1
P4 J3297E COVER GASKET 1
P5 J3297A X’FORMER GASKET 1
P6 J3297B AMP GASKET 1
P7 J3297G BAFFLE GASKET 1
S1 F5010 SCREW FOR SPK 8 xM4xL50 8
S2 F2021 SCREW FOR JACK 9
PLATE 9 xM4xL20
S3 F2509 SCREW FOR X’FORMER 9
PLT 9 xM5xL25
S4 F1618 SCREW FOR HEATSINK 9
#5.8 x 16mm L
S5 F1226 SCREW FOR PORT 7
TUBE 7 xM4xL12
S6 F2507 SCREW FOR BAFFLE 8
8 xM4xL25
S7 F1813 SCREW FOR PLT+X’FORMER 4
BKT/PCB BKT TO HSINK
S8 F1014 SCREW FOR JACK PCB/AMP 8
PCB 5.3 xM3xL10
S9 H120301-308 SCREW FOR PCB TO PCB 3
BKT/IC TO HSINK 3 xL8
S10 F1679 SCREW TO CONTROL PANEL 2
#6.3 x 16mm L (Black)
SUB 6-ELECTRICAL PARTS LIST
Ref. No. Part No. Description Qty.
Capacitors
C101-102 PVE3955-332 ELECT 3300 50V 20% 2
C103 PRE3955-101 COND ELECT 100 uF 50V 20% 1
C104, 901 PRE3952-101 COND ELECT 100 uF 16V 20% 2
C105 PRE3955-220 COND ELECT 22 uF 50V 20% 1
C106, 120 PRM3737-333 COND MYLAR 0.033 uF 100V 5% 2
C107 PRE3954-101 COND ELECT 100 uF 35V 20% 1
C108-109 PRE3954-100 ELECT 10 uF 35V 20% 2
C110 PRE3955-478 COND ELECT 0.47 uF 50V 20% 1
C111 PRE3951-101 COND ELECT 100 uF 10V 20% 1
C112-113 PRE3953-101 COND ELECT 100 uF 25V 20% 2
C114 PRD1335-150 COND DISC 15 pF 50V 5% NPO 1
C115, 121 PRM3737-683 COND MYLAR 0.068 uF 100V 5% 2
C116-117, PRM3737-104 COND MYLAR 0.1 uF 100V 5% 6
C305-308
C118, 301, PRD8035-101 DISC 100 pF 50V 5% 6
904-907 I SL D=5
C119, 125 PRE3955-479 COND ELECT 4.7 uF 50V 20% 2
C122 PRM3737-223 COND MYLAR 0.022 uF 100V 5% 1
C123 PRD8035-100 COND DISC 10pF 50V 5% I SL D=5 1
C160 PRE3954-220 COND ELECT 22 uF 35V 20% 1
C302 PRD8035-300 COND DISC 30pF 50V 5% I SL D=5 1
C303-304 PRD3965-104 DISC 0.1uF 50V +80-20% 2
Y5V/Z5V
Control Sub 6/10
9
