JBL Sub 6 User Manual

1
Powered Subwoofer SUB 6/10
TABLE OF CONTENTS
SPECIFICATIONS..........................................................1
FEATURES.....................................................................1
SUB6/10 DISASSEMBLY PROCEDURES....................2
SUB6/10 CONTROLS ....................................................3
TEST PROCEDURE ......................................................4
SUB6/10 POWERED SUB WOOFER TEST SETUP ...4
SUB 6/10 BLOCK DIAGRAM ........................................5
SUB 6/10 EXPLODED ASSEMBLY VIEW....................6
SUB6 PART LISTS .......................................................9
SUB10 PART LISTS ....................................................12
SUB 6/10 PACKAGING ...............................................15
PRINTED CIRCUIT BOARDS .....................................16
INTEGRATED CIRCUIT DIAGRAMS ..........................19
SUB6 WIRING DIAGRAM ...........................................22
SUB10 WIRING DIAGRAM .........................................23
SUB 6/10 SCHEMATIC DIAGRAM ............................24
SPECIFICATIONS
SUB6 SUB10
Amplifier Power (RMS) .....60Watts .......100Watts
Woofer Size .........6-1/2” ........10”
Inputs ...........Line and Speaker Level . . Line and Speaker Level
Outputs ..........High Pass Speaker Level . . High Pass Speaker Level
Crossover Frequency .....90Hz - 200Hz .....90Hz - 200Hz
(continuously variable)
Frequency Response......40Hz - (90Hz - 200Hz)* . . 38Hz - (90Hz - 200Hz)*
*Determined by crossover setting
External Dimensions
Height ...........17"(432mm) ......24”(608mm)
Width ...........12-3/4” (324mm).....17-3/4” (450mm)
Depth ...........11-1/8” (282mm).....13-1/2” (342mm)
Weight ...........26lbs/11.8 kg .....48lbs/21.8 kg
FEATURES
n
Rugged molded plastic front baffle
n
Adjustable crossover point
n
Adjustable volume control
n
Speaker and Line Level inputs
n
Auto turn-on/turn-off
JBL continually strives to improve its products. New materials, production methods and design refinements are introduced into
existing models without notice as a routine expression of our design philosophy. For this reason, Sub 6/10 may differ in some
respect from their published specifications and descriptions, but will always equal or exceed the original specifications unless
otherwise stated.
