37
VTX B18 | User Manual
16 - ACOUSTIC MEASUREMENTS
FREQUENCY RESPONSE
20 100 1000 10000 20000
Frequency (Hz)
-30
-20
-10
0
10
SPL (dB)
VTX B18 60 VTX B18 80
17 - DIMENSIONS
736.6mm (29.0”)
761.29 mm (29.97”)
546.0mm (21.5”)
