24 Please see operator manual for full details.
A
A
A
A
A
Lubrication points
Fig 25
Fig 26
Fig 27
Steering Ram
Dumper Skip Lift Arm Ram
Dumper Skip Ram
A Grease nipple
A Grease nipple
A Grease nipple
