01 - Machine
03 - Safety
27 - Maintenance Positions
01 - 13 9813/7750-1 01 - 13
27 - Maintenance Positions
Introduction .................................................... 01-13
Health and Safety .......................................... 01-14
Introduction
1. Park the machine on solid, level ground.
2. Install the articulation lock.
3. Move the drive lever to the neutral position.
4. Stop the engine and remove the ignition key.
5. Wait for the specified time to dissipate any
residual hydraulic pressure.
Duration: 30 s
6. Disconnect the battery to prevent accidental
operation of the machine.
7. If necessary, put blocks against the two sides of
the drums before you get below the machine.
Refer to Figure 2.
8. If you wish to arc weld the machine disconnect
the alternator and electronic control units (if
installed).
Figure 2.
