jcb CT160 Service Manual

01 - Machine
09 - Description
12 - Main Component Locations
01 - 21 9813/7750-1 01 - 21
12 - Main Component Locations
Component Identification
Figure 3.
C
E
F
J
K
L
M
H
G
A
B
D
A Engine compartment cover B Instrument panel and switches
C Sunroof D Water tank filler cap
E ROPS (Roll-Over Protective Structure) F Smooth drum (rear)
G Drum drive motor (rear) H Fuel filler cap
J Hydraulic tank oil indicator K Drum drive motor (front)
