RS T4F Diesel Generator
|
G70RS – G125RS 23
Site Installation
The generating set should be located on suitable
foundations. A level concrete surface designed to
carry the weight of the generating set is ideal (if
unsure contact a structural engineer). All electrical
and fuel ducting to and from the machine should
be professionally installed. All wiring to the terminal
box, and through other panels should be installed
using the appropriate cable glands.
The generating set should be located to provide
suitable access for regular maintenance, servicing
and repair work.
Generator sets which are installed outdoors, must
be located in a place which is protected against
weather conditions, dust, etc. as much as possible.
For temporary installations, the generator set can
rest on a well-levelled surface. For long-term
installations, it is advisable to build a concrete base.
B
A
A
B
c
c
c
B
Positioning
A Distance from wall = 1500mm
B Air inlet
C Air outlet
Fig 13
