TECHNICAL DATA
SPECIFICATIONS
Weight - no bar, chain, fuel [kg or (lb)] 4.7 or (10.36)
Weight - with bar and chain, no fuel [kg or (lb)] 5.4 or (11.90)
Fuel tank volume [cm
3
or (L)] 340 or (0.34)
Lubricant tank volume [cm
3
or (L)] 192 or (0.192)
Bar length [cm or (inch)] 40 or (16)
Usable cutting length [cm or (inch)] 37 or (14.57)
Chain pitch [mm or (inch)] 9.53 or (0.375)
Chain gauge [mm or (inch)] 1.27 or (0.05)
Chain type 3/8" low profi le full
complement
Drive sprocket 6 teeth x 3/8"
Engine displacement [cm
3
or (L)] 42 or (0.042)
Maximum engine power (ISO 7293) (kW) 1.7
Maximum engine speed with attachment (r/min) 11,000
Maximum engine speed with attachment (r/min) (reference) 12,500
Idling engine speed (r/min) 2,600-3,600
Specifi c fuel consumption at maximum engine power [g/
kW.h or (L/kW.h)]
426 or (0.587)
NOISE INFORMATION (ISO 22868)
Sound pressure level LpAav:101dB(A),
KpA=3 dB(A)
Sound power level dB(A) 112
VIBRATION INFORMATION (ISO 22867)
Front handle Carlton / Oregon
8.2 m/s
2
, K=1.5
Rear handle Carlton / Oregon
7.7 m/s
2
, K=1.5
