Interior Switches
Ignition Switch
This is a three position rotary switch, operated by the starter key. The starter key can only be removed in the
O position.
Do not operate the starter motor for more than 20s without the engine firing. Let the starter motor cool for at
least 2min between starts.
To warm the glow plugs before you start the engine, turn the ignition key to a position halfway between IGN and
S, then hold it in this position. Then to start the engine, turn the ignition key to the S position. In temperatures
below -20°C (-4.0°F) warm the glow plugs for 50s before you start the engine.
Table 4. Ignition Switch
Position Function
0 Turn the starter key to this position to stop the en-
gine. Make sure the drive is in neutral, the attach-
ment is lowered and the park brake is applied before
stopping the engine.
IGN Turn the starter key to this position to connect the
battery to all the electrical circuits except the lights
and hazard warning circuit. (The lights and hazard
warning circuits are permanently live.) The starter
key will spring back to this position when it is re-
leased from position S.
S Turn the starter key to this position to start the en-
gine. (Operates the starter motor which turns the en-
gine).
Figure 12.
Multi-Purpose Switch
Direction Indicators
Push the stalk forwards to indicate a left turn. Pull the stalk backwards to indicate a right turn. Place in central
position to cancel.
Windscreen Wiper
Rotate the switch barrel to activate and cancel the windscreen wipers. The wiper speed can vary dependant
on machine specification.
Single Speed (Standard)
0 = Off
