AV In 1 / AV In 2
AV In 1
AV In 1 is used for playback of audio/video from an external device connected to
the unit through a 3.5mm jack located on the front panel. The unit can increase
or decrease the volume of the connected device. All other controls are done on
the connected device.
AV In 1 Screen (No Signal)
AV In 2
AV In 2 is used for playback of audio/video from an external device connected
through RCA connectors located on the back of the unit. The unit can increase or
decrease the volume of the connected device. All other controls are done on the
connected device.
AV In 2 Screen (No Signal)
NOTE: Audio/Video devices must be connected to this unit using an audio/
video adapter cable that is available separately.
NOTE: Video will only play when the vehicle parking brake is engaged. The
parking brake wire must be connected for this feature to operate.
Connecting External Devices
