TEC Series BACnet® MS/TP Network Temperature and Humidity Controllers Technical Bulletin22
TEC26x7-4 and TEC26x7-4+PIR Series Thermostat Controllers
Table 5: TEC26x7-4 and TEC26x7-4+PIR Series MS/TP Bus Objects (Part 1 of 4)
Point Name Thermostat Point
(Type/Address)
Range
Room Temp
1, 2
AV 7 -40.0°F/-40.0°C to
122.0°F/50.0°F
Room Temp Override
3
BV 8 0 = Normal
1 = Override
Outdoor Temperature
3, 4
AV 9 -40.0°F/-40.0°C to
122.0°F/50.0°F
Supply Temperature
5
AI 12 -40.0°F/-40.0°C to
122.0°F/50.0°F
AUX Command
3
BV 14 0 = Off
1=On
Sequence of Operation
3
MSV 15 1 = Cooling Only
2 = Heating Only
3 = Cooling and Reheat
4 = Heating and Reheat
5 = Cool/Heat Four-Pipe
6 = Cool/Heat Four-Pipe and Reheat
System Mode
3
MSV 16 1 = Off
2 = Cool
3 = Heat
4=Auto
Occupancy Command
3
MSV 18 1 = Resume Schedule
2 = Occupied
3 = Unoccupied
4 = Temporary Occupied
Keypad Lockout
3
MSV 19 1 = Level 0
2 = Level 1
3 = Level 2
4 = Level 3
5 = Level 4
6 = Level 5
PI Heating Demand
5
AV 21 0 to 100%
PI Cooling Demand
5
AV 22 0 to 100%
AUX (BO5) Status
5
BI 25 0 = Off
1=On
Heating (BO3 and BO4) Valve
Status (TEC2627-4 Model)
5
MSV 26 For On/Off Control:
1=Open
2 = Closed
For Floating Control:
1 = Stopped
2 = Opening
3 = Closing
Cooling (BO1 and BO2) Valve
Status (TEC2627-4 Model)
5
MSV 27 For On/Off Control:
1=Open
2 = Closed
For Floating Control:
1 = Stopped
2 = Opening
3 = Closing
BI1 Status
5, 6
BI 29 0 = Deactivated
1 = Activated
