Table 15: TE-6300 Series Temperature Sensors (order separately)
Sensor type Mounting style Probe length Product code number
Adjustable 8 in. (203 mm) TE-6341A-1
Duct 8 in. (203 mm) TE-6341P-1
4 in. (102 mm) TE-634GV-2Flange
8 in. (203 mm) TE-6341V-2
Outside air 3 in. (76 mm) TE-6343P-1
Wall
2
n/a TE-6344P-1
8 in. (203 mm) TE-6342M-1
Thermistor (2.2k ohm)
Well
6 in. (152 mm) TE-634AM-2
Adjustable 8 in. (203 mm) TE-6361A-1
4 in. (102 mm) TE-636GM-1
TE-6361M-18 in. (203 mm)
TE-6361P-1
Duct
18 in. (457 mm) TE-636JM-1
4 in. (102 mm) TE-636GV-2Flange
8 in. (203 mm) TE-6361V-2
TE-6360F-0Flush n/a
TE-6360F-1
Outside air 3 in. (76 mm) TE-6363P-1
Strap-mount 3 in. (76 mm) TE-636S-1
6 in. (152 mm) TE-636AM-2
Thermistor (10k ohm) Type
II
Well
8 in. (203 mm) TE-6362M-1
1 Two TE-6001-8 Element Holders come with the platinum-equivalent averaging sensors. Order separately to use with a nickel
averaging sensor.
2 Order the TE-1800-9600 Mounting Hardware separately to mount the wall unit to a wallbox.
Troubleshooting
Table 16: Fault list
Faults Probable causes Solutions
Remote Zone Temp Fail The External Zone Temperature
sensor has been disconnected or has
failed.
1. Check the wiring of the sensor.
2. If intentionally disconnected, reset sensors
through the menu.
3. If the problem persists, order replacement
units and return the affected devices to
Johnson Controls under the RMA program.
Supply Temp Fail The External Supply Temperature
sensor has been disconnected or has
failed.
1. Check the wiring of the sensor.
2. If intentionally disconnected, result fault
by entering the menu, enter Control Setup,
and select Inputs to reset the sensors.
3. If the problem persists, order replacement
units and return the affected devices to
Johnson Controls under the RMA program.
Internal Sensor Fail An internal sensor has failed on the
TEC.
Order replacement units and return the
affected devices to Johnson Controls under the
RMA program.
TEC3000 Series Proportional Fan Coil Thermostats Installation Guide 33
