38 – Canadian
TECHNICAL DATA
RECOMMENDED CUTTING EQUIPMENT FOR CANADA
The following is a list of recommended cutting equipment for Class 1A and 1B Chainsaws. The combinations of powerhead, bar
and chain meet all requirements outlined in the CSA Z62.1-95 Chainsaws and Z62.3-96 Chainsaw Kickback standards.
The guide bar nose radius is determined by either the maximum number of teeth in the nose sprocket or the corresponding
maximum nose radius of a solid bar.
As we are listing the maximum guide bar nose radius, you may use a guide bar with smaller nose radius than in our list. For guide
bars of the same length, all sprocket-nose guide bars of the same pitch and having the same number of sprocket teeth may be
considered to have equivalent kickback energy.
A hard nose bar having the same length and nose radius as a sprocket-nose bar may be considered to have equivalent or less
kickback energy than the sprocket-nose bar.
We recommend that you as replacement use the listed bars and chains or ”Type C Low-Kickback Saw Chains” which are available
at your dealer.
Note: For the chains above you are free to choose between 0,050", 0,058" and 0,063" gauge drive link for the corresponding bar,
see the table below.
Saw chain filing and file gauges
Bar Chain
Length, inch Pitch, inch Gauge, inch Max. nose radius Type Drive link count
13 0,325 1,3 10T Jonsered H30 56
15 0,325 10T 64
16 0,325 10T 66
18 0,325 10T 72
13 0,325 1,5 10T Jonsered H25 56
15 0,325 10T 64
16 0,325 10T 66
18 0,325 10T 72
0,050"/1,3 mm S30/95VP 20BP
0,058"/1,5 mm - S25/21BP
0,063"/1,6 mm - 22BP
