WARNING :
Be sure to perform the angle adjustment of the machine head by the operation below before using
the machine head.
2
3
4
BA
21
1) Simultaneously pressing switch
1
and switch
2
,
turn ON the power sw
itch.
2) is displayed
A
in the indicator and the
mode is changed over to the adjustment mode.
3) Turn the handwheel by hand and angle
B
is dis-
played
in the indicator when the reference signal
has been detected.
(The value
is the reference value.)
4) In this state, align the white dot
2
of the hand-
wheel with the concave
3
of the handwheel
cover as shown in the gure.
5) Press switch
4
to nish the adjustment work.
(The value is the reference value.)
5. ADJUSTING THE MACHINE HEAD
(DIRECT-DRIVE MOTOR TYPE SEWING MACHINE ONLY)
