V.35 DTE Cable Pinout

Table 72: V.35 DTE Cable Pinout

DescriptionLFH-60 PairingM/34 PinLFH-60 Pin

Frame Ground–A15

Signal Ground–B57

Request to Send–C48

Clear to Send–D37

Data Set Ready–E9

Received Line Signal Detector–F13

Data Terminal Ready–H33

Test Mode–K41

Transmit Data (A)59P60

Receive Data (A)2R1

Transmit Data (B)60S59

Receive Data (B)1T2

Terminal Timing (A)51U52

Receive Timing (A)6V5

Terminal Timing (B)52W51

Receive Timing (B)5X6

Transmit Timing (A)55Y56

Transmit Timing (B)56AA55

–––22 to 21

–––26 to 25

–––18 to 17

232 ■ Serial PIM Cable Specifications

J2320, J2350, J4350, and J6350 Services Router Getting Started Guide
