4. Start your asynchronous terminal emulation application (such as Microsoft Windows HyperTerminal) and select the
appropriate COM port to use (for example, COM1).
5. Verify that the serial port settings are set to the default:
•
Baud rate—9600
•
Parity—N
•
Data bits—8
•
Stop bits—1
•
Flow control—none
NOTE: You can also connect to the SRX345 using a mini-USB console port. See the SRX345 Hardware Guide.
Perform Initial Configuration
1. Login as the root user and start the CLI. You don't need a password if you're running the factory default.
login: root
root@%cli
root>
NOTE: You can view the factory-default settings with the show configuration operational mode command.
2. Enter configuration mode.
root> configure
[edit]
root#
3. Since you're doing the initial configuration manually, you'll need to remove ZTP from the configuration. This stops the
periodic log messages that report on ZTP status.
Set the root authentication password and commit the change to deactivate ZTP.
[edit]
root# delete chassis auto-image-upgrade
root# delete system phone-home
root# set system root-authentication plain-text-password
New password: password
8

Juniper SRX345 Specifications

General

USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	8
Flash memory	8000 MB
Internal memory	4000 MB
Certification	FCC A, RoHS 2
Rack capacity	1U
Heat dissipation	420 BTU/h
Power consumption (typical)	122 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, MPLS, OSPF, RIP-1, RIP-2
Supported network protocols	IPv4, IPv6
Firewall security	Yes
Security algorithms	IPSEC, SSL/TLS
Networking standards	IEEE 802.1p
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Weight	4900 g
Dimensions (WxDxH)	440.9 x 370.1 x 43.6 mm
