7. Connue to support the device and slide the rear mounng blades into the channel of the side mounng rails and

securing the blades to the rack. Use the four mounng screws (cage nuts and washers if the rack requires) to aach

each blade to the rack.

8. Aach a grounding cable to earth ground and then aach it to the chassis grounding points.

Connect the SRX4600 to Ground

To connect the Firefall to the ground:

1. Aach an ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the chassis.

2. Connect one end of the grounding cable to a proper earth ground, such as the rack in which the services gateway is

mounted.

3. Place the grounding lug aached to the grounding cable over the protecve earthing terminal on the protecve

earthing terminal bracket.

4. Secure the grounding lug to the protecve earthing terminal with the washers and screws.

5. Dress the grounding cable and ensure that it does not touch or block access to other device components and that it

does not drape where people could trip over it.

Connect Power to the SRX4600

IN THIS SECTION

Connect Power to an AC-powered SRX4600 | 4

Connect Power to a DC-powered SRX4600 | 4

Juniper SRX4600 User Manual

Other manuals for Juniper SRX4600
