Juniper SRX650 Datasheet

6
IPv6
4
• OSPFv3
• IPv6 Multicast Listener Discovery (MLD)
• BGP
• Quality of service (QoS)
Wireless
• CX111 Cellular Broadband Data Bridge supported on all branch
SRX Series devices
• 3G ExpressCards supported on SRX210 with built-in
ExpressCard slot
• AX411 Wireless LAN (WLAN) Access Point supported on all
branch SRX Series devices
SLA and Measurement
• Real-time performance monitoring (RPM)
• Top talkers (sessions, packets, bandwidth usage)
• J-Flow flow monitoring and accounting services
Logging and Monitoring
• Syslog
• Traceroute
Administration
• Juniper Networks Network and Security Manager support
• Juniper Networks STRM Series Security Threat Response
Managers support
• Juniper Networks Advanced Insight Solutions support
• External administrator database (RADIUS, LDAP, SecureID)
• Auto configuration
• Configuration rollback
• Rescue configuration with button
• Commit confirm for changes
• Auto record for diagnostics
• Software upgrades
• J-Web
Product Comparison
SRX100 SRX210 SRX240 SRX650
Maximum Performance and Capacity
Junos OS version tested Junos OS 10.0 Junos OS 10.0 Junos OS 10.0 Junos OS 10.0
Firewall performance (large packets) 650 Mbps 750 Mbps 1.5 Gbps 7 Gbps
Firewall performance (IMIX) 200 Mbps 250 Mbps 500 Mbps 2.5 Gbps
Firewall + routing PPS (64 Byte) 75 Kpps 80 Kpps 200 Kpps 900 Kpps
AES256+SHA-1/3DES+SHA-1 VPN performance 65 Mbps 75 Mbps 250 Mbps 1.5 Gbps
IPsec VPN Tunnels 128 256 1,000 3,000
IPS (intrusion prevention system) 60 Mbps 80 Mbps 250 Mbps 900 Mbps
Antivirus 25 Mbps 30 Mbps 85 Mbps 350 Mbps
Connections per second 2,000 2,000 9,000 30,000
Maximum concurrent sessions
DRAM options
16 K / 32 K
5
512 MB8 / 1 GB DRAM
32 K / 64 K
5
512 MB / 1 GB DRAM
64 K / 128 K
5
512 MB / 1 GB DRAM
512 K
6
2 GB DRAM
Maximum security policies 384 512 4096 8192
Maximum users supported Unrestricted Unrestricted Unrestricted Unrestricted
Network Connectivity
Fixed I/O 8 x 10/100 2 x 10/100/1000BASE-T
+ 6 x 10/100
16 x 10/100/1000BASE-T 4 x 10/100/1000BASE-T
I/O slots N/A 1 x SRX Mini-PIM 4 x SRX Mini-PIM 8 x GPIM or multiple
GPIM and XPIM
combinations
Services and Routing Engine slots N/A N/A N/A 2
3
ExpressCard slot (3G WAN) No Yes No No
WAN/LAN interface options N/A See ordering information See ordering information See ordering information
Optional maximum number of PoE ports N/A Up to 4 ports of
802.3af with
maximum 50 W
Up to 16 ports of
802.3af/at with
maximum 150 W
Up to 48 ports of
802.3af/at with
maximum 247 W
USB 1 2 2 2 per SRE
Routing
BGP instances 5 10 20 64
BGP peers 8 16 32 256
BGP routes 4 K / 8 K
5
8 K / 16 K
5
32 K / 64 K
5
1 M
6
OSPF instances 4 10 20 64
OSPF routes 4 K / 8 K
5
8 K / 16 K
5
32 K / 64 K
5
1 M
6
RIP v1 / v2 instances 4 10 20 64
RIP v2 routes 4 K / 8 K
5
8 K / 16 K
5
32 K / 64 K
5
1 M
6
Static routes 4 K / 8 K
5
8 K / 16 K
5
32 K / 64 K
5
1 M
6
