2No. 52016

AV-21W83

AV-21W93

AV-21W93B

SPECIFICATIONS

Design & specifications are subject to change without notice.

Dimensions (W × H × D)

64.9cm × 46.55cm × 47.15cm

64.9cm × 47.8cm × 47.15cm

Mass 26kg 29kg

TV RF System B, G B, G, I, D, K, K1, M

Colour System TV Mode PAL / SECAM PAL / SECAM / NTSC3.58 / NTSC4.43

VIDEO Mode PAL / SECAM / NTSC3.58 / NTSC4.43

Stereo System Playback only (RF A2 BILINGUAL only) A2 / NICAM (B/G, I, D/K) system

Receiving Frequency VHF (VL) 46.25MHz – 140.25MHz (AS0 – S6)

VHF (VH) 147.25MHz – 423.25MHz (S7 – S36)

UHF 431.25MHz – 863.25MHz (S37 – CHINA 57)

CATV ● Cable TVs of Mid (X-Z, S1-S10)

Super (S11-S20) & Hyper (S21-S41) bands receivable

Intermediate VIF Carrier 38.0MHz

Frequency 32.5MHz (5.5MHz) 31.5MHz (6.5MHz)

SIF Carrier 32.0MHz (6.0MHz)

32.5MHz (5.5MHz)

33.5MHz (4.5MHz)

Colour Sub Carrier Frequency PAL (4.43MHz), SECAM (4.40625MHz / 4.25MHz)

NTSC (3.58MHz / 4.43MHz)

Aerial Input Terminal 75Ø Unbalanced

Power Input AC110 – 240V, 50 / 60Hz

Power Consumption 126W

(Max.)

/ 81W

(Avg.)

150W

(Max.)

/ 93W

(Avg.)

Picture Tube Visible size : 51cm measured diagonally

High Voltage 29.0kV ± 1.5kV (at cut-off in service mode)

Speaker 6.5 X 13cm Oval type x 2 6.5 X 13cm Oval type x 2

φ 13cm (BASS BLASTER UNIT)

Audio Output 7W + 7W 7W + 7W + 13W

Video / Audio Input (1 / 2 / 3) Video(1,3) : 1Vp-p, 75Ø (RCA pin jack)

Audio(1,2,3) : 500mVrms ( -4dBs ), High Impedance (RCA pin jack)

Component Input ( Input 2 )

Y: 1Vp-p positive (negative sync provided, when terminated with 75Ø)

CB/CR : 0.7Vp-p 75Ø

Video/Audio Output 1Vp-p, 75Ø (RCA pin jack)

500mVrms(-4dBs)

Low impedance (400Hz when modulated 100%) (RCA pin jack)

Headphone Jack Stereo mini jack (3.5φ)

Remote Control Unit RM-C1016-1H RM-C1011-1H RM-C1012-1H

(Battery size: AA/R06/UM-3 × 2)

Items

AV-21W93/BK

Contents

AV-21W83/BK AV-21W93B/BK
