JVC DLA-RS35 User Manual

6
Others
54
RS-232C Interface (Continued)
■
Remote control code
●
Binary code is sent during communication.
Remote control button
name
Binary code
Remote control button
name
Binary code
37 33 30 31 TEST 37 33 35 39
37 33 30 32 CINEMA 3 37 33 36 36
BACK 37 33 30 33 STAGE 37 33 36 37
ON 37 33 30 35 CINEMA 2 37 33 36 38
STAND BY 37 33 30 36 CINEMA 1 37 33 36 39
HIDE 37 33 31 44 NATURAL 37 33 36 41
LENS.AP. 37 33 32 30 DYNAMIC 37 33 36 42
MENU 37 33 32 45 USER 1 37 33 36 43
OK 37 33 32 46 USER 2 37 33 36 44
LENS 37 33 33 30 THX 37 33 36 46
37 33 33 34 HDMI 1 37 33 37 30
37 33 33 36 HDMI 2 37 33 37 31
MENU POSITION 37 33 34 32 PIC.ADJ. 37 33 37 32
PC 37 33 34 36 GAMMA 37 33 37 35
VIDEO 37 33 34 41 C.TEMP 37 33 37 36
S-VIDEO 37 33 34 42 ASPECT 37 33 37 37
COMP. 37 33 34 43
