53
SPECIFICATIONS
GENERAL
Format : VHS PAL standard
Power source : DC 6V
Power consumption
GR-AX760 light on : 8.7 W
GR-AX760 light off : 5.7 W
GR-AX660 : 5.7 W
Signal system : PAL-type
Video recording system
Luminance : FM recording
Colour : Converted sub-carrier
direct recording
*Conforms to VHS
*standard
Cassette : VHS-C cassette
Tape speed
SP : 23.39 mm/sec
LP : 11.70 mm/sec
Recording time Max.
SP : 60 minutes
(with EC-60 cassette)
LP : 120 minutes
(with EC-60 cassette)
Operating temperature : 0°C to +40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to +50°C
Weight
GR-AX760 : Approx. 810 g
GR-AX660 : Approx. 800 g
Dimensions
(Including viewfinder) : 109 (W) x 113 (H)
x 226 (D) mm
CAMERA
Pick up : 1/4” format CCD
Lens : F1.2, f = 4.1 to 57.4 mm,
14:1 power zoom lens
with auto iris and macro
control, filter diameter
46 mm
Viewfinder : Electronic viewfinder
with 0.5” black/white
CRT
White balance
adjustment : Auto/Manual adjustment
VIDEO
Output : 1 Vp-p, 75 ohms,
unbalanced (via VIDEO
out connector)
AUDIO
Output : –8 dBs, 1 k-ohm (via
AUDIO out connector)
AC POWER ADAPTER/BATTERY CHARGER
(AA-V11EK) SPECIFICATIONS
Power requirement : AC 110 to 240 V`,
50/60 HZ
Power consumption : 23 W
Output
Charge : DC 8.5 V , 1.3 A
VTR : DC 6.3 V , 1.8 A
Charging system : Constant current, peak
detection, timer
controlled
Dimensions : 150 (W) x 42 (H)
x 68 (D) mm
Weight : Approx. 400 g
CASSETTE ADAPTER (C-P7U)
SPECIFICATIONS
Dimensions : 188 (W) x 25 (H)
x 104 (D) mm
Weight : Approx. 240 g
Accessory : “R6 (AA)”-size battery x 1
Provided Accessories ...................... Z pg. 4
Optional Accessories
•Battery Packs BN-V12U, BN-V22U, BN-V25U
•Car Battery Charger BH-V3E
•Car Battery Cord AP-V7E
•RF Unit RF-V5E
•Compact VHS-C Cassettes EC-60/45/30
•Active Carrying Bag CB-V7U
* Some acccessories are not available in some
areas. Please consult your nearest JVC dealer for
details on accessories and their availability.
Specifications shown are for SP mode unless
otherwise indicated. E. & O. E. Design and
specifications subject to change without notice.
