JVC GR-D350UC User Manual

2-42(No.YF123)
<MAIN>
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
MODE
REC PLAY
PIN NO.
IC1001 - -
IC1002
1 2.9 2.9
2 2.6 2.7
3 0.3 0.3
4 3.0 3.1
5 3.1 3.1
6 3.1 3.1
7 0 0
8 1.4 1.4
9 0 0
10 0 0
11 0 0
12 0 0
13 0 0
14 0 0
15 0 0
16 0 0
17 0 0
18 0 0
19 3.0 3.0
20 2.8 2.8
IC1004
1 1.5 0
2 0 0
3 1.3 0
4 0 0
5 3.0 3.0
IC1005
1 3.1 3.1
2 0.8 0.9
3 3.1 3.1
4 0 0
5 3.1 3.1
6 3.1 3.1
7 3.1 3.1
8 3.0 3.1
IC1006
1 0 0
2 3.0 3.0
3 3.0 3.0
4 0 0
5 3.0 3.0
6 0.5 0.5
7 0.6 0.6
8 3.0 3.1
IC1007
1 3.0 3.0
2 3.0 3.0
3 0 0
4 0 0
IC1601
1 0 0
2 0.5 0.7
3 0.3 0
4 0 0
5 0.5 0.5
6 0 0
7 0 0
8 0 1.5
9 1.5 1.5
10 1.5 1.5
11 1.5 1.5
12 1.5 1.5
13 1.5 1.5
14 2.8 2.8
15 1.2 1.2
16 1.5 0
17 1.5 1.5
18 1.4 1.5
19 1.5 1.5
20 1.5 1.5
21 3.1 3.1
22 0.7 0.6
23 0.4 0.4
24 1.4 1.4
25 1.4 1.4
26 11.0 11.0
27 0 0
28 0 0
29 0.7 0.7
30 0 1.3
31 0.7 0.7
32 0.8 0.9
33 1.3 1.3
34 1.2 1.3
35 1.3 1.3
36 0 0
37 1.3 1.3
38 0 0
39 1.5 1.5
40 0 0
41 0 0
42 0 0
43 0 0
44 0 0
45 4.6 0
46 1.5 0
47 1.4 1.5
48 1.5 0
49 0 1.5
50 0 0
51 0 14.1
52 0 2.3
53 0 12.5
54 0 0
55 0 0
56 0 0
57 0 3.0
58 0 2.9
59 0 0
60 0 1.1
61 0 0.3
62 0 1.5
63 0 0.7
64 0 0.9
IC1701
1 - -
2 1.5 1.4
3 1.4 1.5
4 0 0
5 1.5 1.5
6 1.5 1.5
7 - -
8 4.8 4.8
IC1702
1 - -
2 1.5 1.5
3 1.4 -
4 0 0
5 - -
6 1.4 1.5
7 - -
8 4.8 4.8
IC2201
1 0 1.5
2 0 0
3 0.1 1.6
4 3.0 3.1
5 3.1 3.1
6 0 0
7 1.5 1.5
8 1.5 1.4
9 1.5 1.5
10 1.2 0.7
11 1.4 1.4
12 2.5 2.6
13 1.3 1.4
14 1.5 0
15 0 0
16 0 0
17 0 0
18 0 0
19 3.0 3.1
20 0 0
21 0.9 0.5
22 1.5 1.5
23 0.8 0.7
24 1.5 1.5
25 0 0
26 0 0
27 4.8 4.8
28 0 0
29 2.4 2.4
30 0 0
31 3.1 3.0
32 1.4 1.5
33 0.9 1.5
34 0.9 1.5
35 0 1.5
36 1.5 1.5
37 1.5 1.5
38 1.5 1.5
39 1.5 0.1
40 1.5 0
41 0 0
42 4.8 4.8
43 3.4 0
44 4.7 4.8
45 1.5 0
46 1.5 0
47 1.5 1.5
48 1.5 1.5
IC3001 - -
IC3004
1 0 0
2 1.3 1.2
3 1.9 1.9
4 2.9 2.9
5 1.4 1.4
6 1.2 1.2
7 1.4 0
8 2.3 2.4
9 3.1 3.0
10 3.0 3.0
11 0 0
12 3.0 3.0
13 0 2.9
14 0.3 0
15 1.0 0.9
16 0 0
IC3201
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
9 0 0
10 0 0
11 0 0
12 0 0
13 0 0
14 0 0
15 0 0
16 0 0
17 0 0
18 0 0
19 0 0
20 0 0
21 0 0
22 0 0
23 0 0
24 0 0
25 0 0
26 0 0
27 0 0
28 0 0
29 0 0
30 0 0
31 1.0 1.0
32 0 0
33 0 0
34 0 0
35 0 0
36 0 0
37 0 0
38 0 0
39 0 0
40 1.0 1.0
41 0 0
42 0 0
43 0 0
44 0 0
45 0 0
46 0 0
47 0 0
48 0 0
49 0 0
50 0 0
51 0 0
52 0 0
53 0 0
54 0 0
55 0 0
56 0 0
57 0 0
58 0 0
59 0 0
60 0 0
61 0 0
62 0 0
63 0 0
64 0 0
IC3501
1 0 0
2 0.5 0.6
3 0 0
4 0 1.5
5 2.5 2.5
6 2.1 1.4
7 1.4 0
8 0 0
9 1.1 3.1
10 1.4 1.4
11 3.1 3.0
12 0 0
13 4.6 4.8
14 0 0
15 0 0
16 0 0
17 0 0
18 3.7 1.6
19 3.4 1.6
20 3.4 1.6
21 3.7 1.6
22 0 0
23 3.7 1.6
24 3.5 1.7
25 3.5 1.6
26 3.7 1.7
27 0 0
28 1.6 2.0
29 3.5 1.7
30 3.4 1.7
31 1.6 2.0
32 0 0
33 0 0
34 0 0
35 1.7 1.7
36 0.4 0.4
37 0 3.1
38 0 3.1
39 0 3.1
40 1.7 1.5
41 0 3.1
42 3.1 0
43 4.6 4.8
44 3.0 0
45 0 0
46 1.0 2.0
47 0 2.0
48 4.5 3.1
49 4.3 2.9
50 0.5 0
51 1.2 1.2
52 0.5 1.6
53 0 0
54 3.2 2.5
55 2.5 1.9
56 0.5 1.1
57 2.4 1.9
58 2.5 1.3
59 0 0
60 1.2 1.2
61 3.0 1.9
62 2.5 1.9
63 2.5 1.4
64 2.4 1.9
IC3702
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
IC4201 - -
IC4901
1 2.1 2.1
2 2.1 2.1
3 2.0 2.1
4 4.8 4.8
5 2.1 2.1
6 2.1 2.1
7 1.6 2.2
8 - 2.1
9 2.1 2.1
10 2.1 2.1
11 0 0
12 0.2 0
13 0.2 0
14 0.8 0.2
IC4902
1 1.8 1.8
2 1.9 1.9
3 1.9 1.9
4 0 0
5 1.9 1.9
6 1.9 1.9
7 1.9 1.9
8 4.8 4.8
IC4903
1 2.1 0.6
2 2.1 3.0
3 2.1 2.0
4 0 0
5 2.1 2.1
6 2.1 2.1
7 2.1 3.5
8 4.8 4.8
IC4904
1 1.7 4.0
2 1.7 2.3
3 1.7 3.0
4 0 0
5 2.0 2.0
6 3.7 2.1
7 3.8 2.1
8 4.8 4.8
IC4951
1 0.6 0.6
2 0 0
3 1.5 1.5
4 1.5 1.5
5 0 0
6 3.0 3.0
7 0 0
8 3.0 3.0
9 0 0
10 3.0 3.0
11 1.4 1.4
12 3.0 3.0
13 4.8 4.8
14 0.1 0
15 0 0
16 0 0
17 1.0 1.0
18 4.8 4.8
19 0 0
20 0 0
21 0 0
22 1.0 1.0
23 1.0 1.0
24 0 0
25 0.9 0.8
26 4.8 4.8
27 0 0
28 0 0
29 0 0
30 0 0
31 0 0
32 0 0
33 0 0
34 0 0
35 4.8 4.8
36 0.9 0.8
37 0 0
38 0.9 1.0
39 0.9 1.0
40 0 0
41 0 0
42 0 0
43 4.8 4.8
44 0.9 1.0
45 0 0
46 0 0
47 0 0
48 4.8 4.8
IC6001
1 0 0
2 7.6 7.8
3 0 0
4 9.2 9.2
5 0 0
6 8.6 8.5
7 9.7 9.7
8 7.7 7.7
9 6.2 6.1
10 0 0
11 10.6 10.8
12 11.5 11.8
13 8.5 8.5
14 0.5 0.8
15 0.7 0.7
16 0.5 0.9
17 0 0
18 0 3.1
19 10.5 11.0
20 11.0 11.0
21 0 0
22 0 0
23 3.0 3.0
24 3.1 3.0
25 3.1 3.0
26 3.1 3.0
27 3.1 3.1
28 3.1 3.1
29 1.0 1.0
30 0 0
31 0 0
32 0 0
33 0 0
34 2.7 2.7
35 0 0
36 0 0
37 1.0 1.0
38 0.5 0.9
39 1.0 1.0
40 0.7 0.8
41 0 0
42 0 0
43 0.5 0.6
44 0.3 0.3
45 0.3 0.3
46 0.7 0.7
47 1.0 1.0
48 0.7 0.7
49 1.0 1.0
50 0.6 0.8
51 0.6 0
52 0.5 1.0
53 0 0
54 0 0
55 1.0 1.0
56 3.1 3.1
57 1.7 1.7
58 2.6 2.7
59 2.7 2.7
60 1.1 1.1
61 15.0 15.0
62 10.6 10.8
63 2.7 2.7
64 11.0 11.0
IC7801
1 3.1 3.1
2 1.5 1.5
3 0 0
4 0 0
5 3.0 3.1
6 3.0 3.0
7 1.1 0.7
8 2.5 2.5
9 0 0
10 0 0
11 3.1 3.1
12 3.1 3.1
13 3.1 3.1
14 0 0
15 0 0
16 0 0
17 0 0
18 0 0
19 0 0
20 0 0
21 0 0
22 0 0
23 0 0
24 0 0
25 0 0
26 0 0
27 0 0
28 0 0
29 0 0
30 0 0
31 0 0
32 0 0
33 0 0
34 0 0
35 0 0
36 0 0.9
37 0 0
38 0 0
39 0 8.5
40 0 0
41 0 0.9
42 0 0
43 0 0
44 0 1.0
45 0 0
46 0 0.9
47 0 8.5
48 0 4.2
49 0 3.0
50 0 0
51 0 0
52 0.1 0
53 0.7 0
54 0.5 0
55 0.5 0
56 3.0 3.0
57 3.0 3.0
58 0.5 1.5
59 3.0 3.0
60 2.6 2.8
61 0 0
62 0 0
63 0 0
64 0 0
Q1001
E 3.1 3.1
C 0 0
B 3.0 3.0
Q1002
E 0 3.1
C 0 3.0
B 0 0
Q1003
E 3.1 3.1
C 0 -0.5
B - 3.0
Q1005
E 0 0
C 0 0
B 3.0 3.0
Q1006
E 0 0
C 3.1 3.1
B 0.3 0
Q1007
E 0 0
C 0 0
B 3.0 0
Q1601
1 7.8 0
2 0 0
3 0 4.8
4 3.0 0
5 0 4.8
Q2403
E 3.1 3.1
C 4.8 4.8
B 3.7 3.7
Q3001
E 3.2 3.2
C 0 0
B 3.9 3.8
Q3002
1 0.5 2.0
2 0 1.4
3 11.3 5.8
4 0 1.3
5 0.5 2.0
6 0 0
Q3003
1 0.5 0.5
2 0 0
3 0 0
4 0 0
5 0.5 0.5
6 0 0
Q3703
E 0.9 0.9
C 0 0
B 0.3 0.4
Q3705
1 0.9 0.9
2 0.3 0.3
3 0.2 0
4 0 0.9
5 0.3 0.3
6 0.1 0
Q4901
E 0.2 0
C 1.5 2.1
B 0.8 0.4
Q4951
E 0 0
C 3.5 3.5
B 0 0
Q4981
E 0 0
C 4.2 0
B 0 0
Q6101
1 0 7.9
2 0 11.0
3 4.8 0
4 0 3.0
5 4.8 3.0
Q6103
S 3.1 3.1
D 2.5 2.5
G 0.9 0.8
Q6201
1 9.2 9.2
2 11.0 11.0
3 0 0
4 0 1.6
5 1.6 1.6
Q6301
1 8.8 8.8
2 11.0 11.0
3 0 0
4 2.7 2.7
5 2.7 2.7
Q6401
1 9.8 9.7
2 11.0 11.0
3 0 0
4 1.0 1.1
5 1.0 1.1
Q6501
S 11.0 11.0
D 0 0
G 7.7 7.7
Q6505
E -7.6 -7.7
C -15.2 -15.3
B -8.2 -8.2
Q6701
S 11.0 11.0
D 4.8 4.8
G 6.2 6.2
Q6702
S 4.8 4.8
D 0 0
G 9.8 9.8
Q6703
S 4.8 4.8
D 4.8 4.8
G 0 0
Q7701
1 3.4 3.4
2 3.9 4.0
3 14.9 14.9
4 5.0 5.0
5 5.6 5.6
6 5.6 5.6
Q7702
1 3.4 3.4
2 3.9 4.0
3 14.5 14.9
4 5.0 5.0
5 5.6 5.6
6 5.6 5.6
Q7703
1 3.4 3.4
2 0 4.0
3 14.9 14.9
4 5.0 5.0
5 5.6 5.6
6 5.6 5.6
Q7704
1 0 0
2 3.0 3.0
3 14.9 14.9
4 15.0 14.9
5 0 0
6 0 0
<CCD>
MODE
REC PLAY
PIN NO.
IC5001
1 -7.1 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 11.3 10.8
8 14.9 14.9
9 0 12.7
10 0 0
11 -7.5 0
12 0 0
13 1.2 0
14 9.0 9.0
Q5001
E 10.6 0
C 15.0 0
B 11.3 10.8
<MONITOR>
MODE
REC PLAY
PIN NO.
IC7601
1 3.1 3.1
2 3.1 3.1
3 0 0
Q7601
1 1.3 0
2 1.8 1.8
3 1.6 1.6
4 1.1 1.1
5 1.8 1.8
6 0 1.8
Q7602
1 1.1 0
2 1.8 1.8
3 1.7 1.7
4 1.1 1.1
5 1.8 1.8
6 1.6 0
<VF>
MODE
DC
PIN NO.
Q7001
1 0
2 0
3 0
4 0
5 0
6 0
VOLTAGE CHARTS
