EN 9
MasterPage: Start_Right
Getting Started
ENGLISH
Open the pad and make grip adjustments.
● Before making the adjustment, remove any security tags that may be attached to the velcro.
To attach the camcorder to a tripod, align the direction stud and screw to the mounting socket and
stud hole on the camcorder. Then tighten the screw clockwise.
● Some tripods are not equipped with studs.
Attach The Shoulder Strap
Strap Guide
Peel off the pad and thread
the end of the strap through
the eyelet.
Thread the strap through the
buckle, adjust its length, and use
the strap guide to fix it in place.
Position the buckle near
the eyelet and reattach the
pad.
Buckle
Eyelet
Grip Adjustment
Tripod Mounting
BATT
GR-DA20EK.book Page 9 Thursday, August 2, 2007 12:08 PM
