2
1
Grip Adjustment
1
Separate the Velcro strip.
2
Pass your right hand through the loop and grasp
the grip.
3
Adjust so that your thumb and fingers can easily
operate the Recording Start/Stop Button and
Power Zoom Lever. Refasten the Velcro strip.
Viewfinder Adjustment
1
Set the Power Switch to “ ” or “ ” while
pressing down the Lock Button located on the
switch. Set the Shooting Mode Switch to any
position.
2
Pull out the viewfinder fully and adjust it
manually for best viewability.
3
Turn the Dioptre Adjustment Control until the
indications in the viewfinder are clearly
focused.
Dioptre
Adjustment
Control
Power Switch
GETTING STARTED
(cont.)
Shooting Mode
Switch
Shoulder Strap Attachment
1
Following the illustration, thread the strap
through the eyelet 1, then fold it back and
thread it through the buckle 2. Repeat the
procedure to attach the other end of the strap to
the other eyelet 3, making sure the strap is not
twisted.
CAUTION:
When using a tripod, be sure to open and
extend its legs fully to stabilise the
camcorder. To prevent damage to the unit
caused by falling over, do not use a small-
sized tripod.
Tripod Mounting
1
Align the screw and camera direction stud on
the tripod with the camera’s mounting socket
and stud hole. Then tighten the screw.
•Some tripods are not equipped with studs.
Power Zoom Lever
Recording
Start/Stop button
To Next Page
